MAP 0300: Multiaccess Enclosure Basic Verification
You are here because you have a problem on the Multiaccess Enclosure.
001
Check that the Multiaccess Enclosure unit is powered ON.
If not switch the power ON button to the ON position.
Within 2 minutes, check the status of the LEDs on the front of the multiaccess
enclosure.
The LEDs on the multiaccess enclosure should have the following status:
YY
Y
Y
YY
Y
Y
Y
Y
Y
AB 1
5
2
6
3
7
4
8
Table 3-1 on page 3-7 shows the desired status of the LEDs. Table 3-2 on
page 3-8 shows messages that may appear at the operator console attached to the
Multiaccess Enclosure that may indicate a problem.
