12BB230h

Total number of user

addressable sectors

0DD0h (=1,768KB)Buffer size

10hNumber of heads

3FFFhNumber of cylinders

IC25N010ATCS04-0

2542980h

Total number of user

addressable sectors

0DD0h (=1,768KB)Buffer size

10hNumber of heads

3FFFhNumber of cylinders

IC25N020ATCS04-0

37E3E40h

Total number of user

addressable sectors

0DD0h (=1,768KB)Buffer size

10hNumber of heads

3FFFhNumber of cylinders

IC25N030ATCS04-0

4A85300h

Total number of user

addressable sectors

0DD0h (=1,768KB)Buffer size

10hNumber of heads

3FFFhNumber of cylinders

IC25N040ATCS04-0

6FC7C80h

Total number of user

addressable sectors

0DD0h (=1,768KB)Buffer size

10hNumber of heads

3FFFhNumber of cylinders

IC25T060ATCS05-0

CAxOAxxxMicrocode revision

Figure 93. Number of cylinders/heads/sectors by model.

For the microcode revision refer to 13.8, "Identify Device (ECh)" on page 122. This is 8 characters in

ASCII.

Travelstar 60GH & 40GN hard disk drive specifications

130
