13.32.4.5 Error data structure

Data format of error data structure is shown below.

1Ch2Life time stamp (hours)

1Bh1State

08h19Extended error data (vendor specific)

07h1Status register

06h1Device/Head register

05h1Cylinder High register

04h1Cylinder Low register

03h1Sector number register

02h1Sector count register

01h1Error register

00h1Reserved

OffsetByteDescription

Figure 131. Error data structure

State field contains a value indicating the device state when command was issued to the device.

Vendor specificxBh–xFh

Reservedx5h–xAh

S.M.A.R.T. Off-line or Self-testx4h

Active/Idlex3h

Standbyx2h

Sleepx1h

Unknownx0h

StateValue

Note: The value of the x is vendor specific.

Travelstar 60GH & 40GN hard disk drive specifications

179
