Table 34. FRU locations and failing components
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Disk drive backplane 1 Un-P1 No
Disk drive backplane 2 Un-P2 No
Power distribution backplane Un-P3 No
Fan 1 (left) Un-A1 Yes See Fans.
Fan 2 Un-A2 Yes
Fan 3 (right) Un-A3 Yes
VPD card Un-C1 No
Figure 50. I/O enclosure (stand-alone model, back) 7031-T24
Finding parts, locations, and addresses 135
