Table 150. Final assembly (assembly 5) (continued)
Index number CCIN Part number Units Description
23 44P2994 As required Filler plate
23 44P2462 As required Filler plate
24 77G0599 4 Screw
25 74F1823 4 Nut clip
26 74Y0996 As required MDA-EZ assembly
27 15R8873 As required Blower assembly
28 46K3997 1 Light strip (rear)
29 45D2818 1 Connector cover
30 45D7497 1 Node service tool
Table 151. Final assembly (assembly 6)
Index number CCIN Part number Units Description
1 45D8502 As required DCA assembly
2 As required Heat sink (included with the processor
assembly)
3 538F 73Y4115 As required Processor assembly, 8 core with 4cTurboCore
option
270 Finding parts, locations, and addresses
