Table 5. Adapter slot priorities and maximum adapters supported in the EMX0 PCIe3 expansion drawer
(continued)
Feature
code
Description EMX0 PCIe3 expansion drawer
Slot priorities
1
Maximum number of adapters
supported
2
AIX
®
Linux IBM i
EJ0L PCIe3 12 GB Cache RAID SAS
quad-port 6 Gb adapter (FC
EJ0L; CCIN 57CE); Adapter part
number: 00FX840
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C3,
P2-C3, P1-C6, P2-C6
4 4 4
EJ10 PCIe3 x8 LP SAS Tape/DVD
adapter quad port 6Gb (FC EJ10
and EJ11; CCIN 57B4); Adapter
part number: 00MH959
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C3,
P2-C3, P1-C6, P2-C6
4 4 4
EJ14 PCIe3 12 GB Cache RAID+ SAS
adapter quad-port 6 Gb x8 (FC
EJ14; CCIN 57B1); Adapter part
number 01DH742
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C3,
P2-C3, P1-C6, P2-C6
4 4 4
EJ33 4767-001 Crypto- graphic
Coprocessor (FC EJ32 and
EJ33; CCIN 4767); Adapter part
number: 00LV501
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6 P2-C6,
P1-C1, P2-C1, P1-
C4, P2-C4
6 6 6
EJ37 4769-001 Cryptographic
Coprocessor (FC EJ35 and EJ37
for BSC; CCIN C0AF); Adapter
part number: 02JD572
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6 P2-C6,
P1-C1, P2-C1, P1-
C4, P2-C4
6 6 6
EN0S PCIe2 4-port (10 Gb + 1 GbE)
SR+RJ45 adapter (FC EN0S and
FC EN0T; CCIN 2CC3); Adapter
part number: 00E2715
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN0U PCIe2 4-port (10 Gb + 1 GbE)
Copper SFP+RJ45 adapter (FC
EN0U; CCIN 2CC3); Adapter part
number: 00E2715; low-prole
tailstock: 00E2720
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN0W PCIe2 2-port 10 GbE BaseT
RJ45 Adapter
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN1A PCIe3 x8 2-port Fibre Channel
(32 Gb/s)
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6, P2-
C6, P1-C1, P2-C1,
P1-C4, P2-C4
6 6 6
8 Power Systems: Adapter placement for the 9043-MRX
