4. Remove the metal shield from the drive bay by inserting a flat-blade
screwdriver into one of the slots and gently prying it loose.
5. Make sure the drive that you are installing is set correctly as either a master or
a slave device.
Note: A serial ATA hard disk drive does not need to be set as either a master
or a slave device.
v If it is the first CD drive or DVD drive, set it as a master device.
v If it is an additional CD drive or DVD drive, set it as a slave device.
v If it is an additional parallel ATA hard disk drive, set it as a slave device.
Refer to the documentation that comes with your drive for master/slave
jumper information.
6. Install a retainer bracket on the side of the drive.
7. Install the drive into the bay until it snaps into position.
*XXXXXXXXX*
*XXXXXXXXX*
18 User Guide
