System Resources IRQ I/O Address (Hex) Memory Address
(Hex)
DMA
Channel
Video controller None 03BA, 03B4–03B5,
03C0–03CF,
03D4–03D5, 03DA,
A0000–BFFFF
| C0000–CBFFF
None
WSS codec base 5, 7, 9, 10, 11, 15 0530–0537,
0604–060B,
0E80–0E87, or
0F40–0F47
None 0, 1, 3
Note:
1
The I/O addresses in parentheses are used also when ECP is enabled as the printer operating mode from the
ThinkPad Configuration program.
2
When you enable ECP as the printer operating mode from the ThinkPad Configuration program, you must select one
value from the four selections (including “disabled”).
3
When you use Windows 95 OSR2, do not assign this I/O addresses.
96 IBM ThinkPad 600E Online Book
