Inverter Card (Front View)
▌1▐ Light-Emitting Diodes
▌2▐ System Board Connector
2
1
Inverter Card (Rear View)
▌1▐ Light-Emitting Diodes
▌2▐ Infrared Serial Port
▌3▐ LCD Connector
3 21
188 IBM Mobile Systems HMM
