PCIe SAS RAID and SSD adapter locations
The following table provides location codes for parts that comprise the server.
Table 3. FRU location
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
System unit Un
Figure 7. Memory card locations
Figure 8. PCIe SAS RAID and SSD adapter locations
10 Finding parts, locations, and addresses
