Model AMP 480
Mains Voltage 230V , 50 / 60HZ ± 10% switchable Supply
Battery Voltage DC 24V (MAX 10% deviation)
Max : 720W Output power
Rated : 480W
Outputs Speaker outputs: Music/speech: 8ohm,100V(70V/100V Selectable)
Speech: 100V (70V/100V Selectable)
Line output: 1V, 600ohm
Inputs Line input : 1V, 47Kohm / mic 1mV 250 ohm
Frequency response 50HZ ~ 20KHZ ± 3dB
Total harmonic distortion Less than 1% at 1KHZ,rated power.
Signal to noise ratio 80dB below rated power.
Controls Master volume control.
230V Voltage selector switch.
Indicators Power indicator (LED),output level indicators (5 LEDS)
AC power consumption 1100 watts
DC power consumption 768 watts
Dimentions ( H x W x D ) 88 x 430 x 385 mm
Weight Approx 18.0kg
Color Black
Mounting options 19” rack mountable.
Type TWO ZONE Power Amplifier
Model AMP 120 AMP 240
Mains Voltage AC 115V / 230V , 50 / 60HZ ± 10% switchable Supply
Battery Voltage DC 24V (MAX 10% deviation)
Max : 180W 360W Output power
Rated : 120W 240W
Outputs Speaker outputs: Music/speech: ohm,100V(70V/100V Selectable)
Speech: 100V (70V/100V Selectable)
Line output: 1V, 600ohm
Inputs Line input : 1V, 47K ohm / mic 1mV 250 ohm
Frequency response 50HZ ~ 20KHZ ± 3dB
Total harmonic distortion Less than 1% at 1KHZ,rated power.
Signal to noise ratio 80dB below rated power.
Controls Master volume control.
AC 115V / 230V Voltage selector switch.
Indicators Power indicator (LED),output level indicators (5 LEDS)
AC power consumption 400 watts 760 watts
DC power consumption 192 watts 384 watts
Dimensions ( H x W x D ) 88 x 430 x 300 mm
Weight Approx 10.0kg Approx 13.0kg
Color Black
Mounting options Table top or 19” rack mountable.
