22. Technical Specifications EV-5000
(0 dBu = 0.775 RMS)
21.1 EV 5000 Master / Slave
Sensivity Background Music input (BGM) 0 dBu unbalanced
Sensivity AUX input (with request) 0 dBu unbalanced
Sensivity MIC inputs
Input and Master Level adjusted to 0 dB -46 dBu (4 mV)
Audio outputs to amplifiers 4x 0dBu (max. +10dBu) transformer balanced
Audio output to Spare amplifier 1x 0dBu (max. +10dBu) transformer balanced
Frequency response
BGM to amp OUT 25 Hz...20 kHz +2/-3 dB
MIC inputs 28 Hz...20 kHz +2/-3 dB
Total Harmonic Distortion
BGM to outputs for amps 0 dBu 0.05%
+6 dBu 0.05%
+10 dBu 1%
MIC inputs 0 dBu 0.35%
+6 dBu 0.7%
+10 dBu 1%
Signal to Noise ratio BGM IN MIC IN (-46 dBu, 600 Ohm)
78 dB 50 dB
Check Tone frequency 22 kHz
Check Tone MIC capsule 1 kHz
100V switch relays switching voltage 160 V AC max.
switching current 8 A AC (Pmax. = 800 Watts)
Miscellaneus relay contacts 120 V AC max., 2 A AC max.
Display blue, two line, alpha numeric LCD display
Language of display indication German or English, (others on request),
alterable by exchanging an EEPROM
Sound file storage medium SD card, 1 GB max.
Operating voltage 230 V AC, 50 – 60 Hz, 30 VA
Battery voltage 24 V DC, 500 mA max.
Primary fuse 315 mA slow blow
Secondary fuse (inside the device) 1 A slow blow
Temperature range -5°C > T < 55 °C
