ic audio
EV-5000
EN
39
Dimensions W x D x H 140 x 193 x 25/60 mm (front/rear)
Length of gooseneck 380 mm, capsule included
Connecting cable 2.5 Meters, fixed on call station, other end
5-pole DIN connector DIN 41524
Weight 1.2 kg
Colour aluminium natural anodised, side frames red
22.4 EV-EVAC MIC
Microphone type Dynamic capsule, 600 Ohms,
in handheld housing, monitored
Sensivity 2.2 mV/Pa (1 kHz)
Frequency response 150 Hz...12 kHz
Audio output unbalanced, MIC level
Number of addressable zones 1, All Call
Control output Key contact, feed cable monitored
Connecting cable 0.4 m Meter helix cable, fixed on
handheld MIC, other end 5-pole DIN connector
DIN 41524
Dimensions W x H x D 50 x 100 x 45 mm
Weight 0.15 kg
Colour red
22.5 EV-P4
MIC type Dynamic capsule, 600 Ohms, on gooseneck
Sensivity 2.2 mV/Pa (1 kHz)
Frequency response 150 Hz...12 kHz
Audio output balanced floating, MIC level
Number of addressable zones 4
Control outputs 4x key contact
Busy indication red LED
