iCandy apple
26 27 28
29 30 31
32 33 34
iCandy apple carrycot
26. Remove the mattress
27. Remove the inner liner
28. Stay Bars
Slide the support stay bars at front and rear
until under location lugs. Refit the liner and
mattress.
29. Operation of the canopy (hood)
Pull up the handle as illustrated until the
two grey latching buttons (arrowed) engage
with a positive "click". Check that the
handle is secure before placing your baby
into the carrycot.
30. To lower the canopy (hood)
Depress both grey latching buttons as
shown before attempting to rotate the hood
handle.
31, 32 & 33. Attaching the carrycot
to the chassis
Lower the carrycot as shown ensuring both
side grey side buttons latch into place.
Ensure securely positioned by pulling up on
the handle.
Pull down the stabilizer bar and lock onto
the basket bar as shown.
# ,)'/8,%88,)46%1
&3(= 36 7)%8 92-8 %88%',1)28
():-')7 %6) '366)'80= )2+%+)(
&)*36)97)
34. Removal of carrycot
Release and store the stabilizer bar.
Depress each grey side button as shown,
whilst lifting up gently and simultaneously
holding handle. Pull up and clear of chassis
once both sides are released.
35. Carrycot Raincovers
Fit raincover over the hood/canopy area
before fitting over the foot end of carrycot.
Ensure elasticated seams of raincover are
positioned under the base of the carrycot.
%66='38'0)%2-2+-2*361%8-32
The exterior of the carrycot, hood and
apron of the iCandy apple carrycot may be
cleaned with a damp cloth.
The lining and cover must be washed by
hand using a soft detergent at a maximum
temperature of 30 degrees (see instructions
on washing label). Do not place in washing
machine or tumble-dryer!
