Upper/Main seat unit
Assembly & operation is the same
as the single stroller (see Section
2).
Ensure that the seat
frame movement mechanism is
taken out of the store/transport
position prior to tting (see page
8).
Fit the screws
supplied to the upper/main seat
unit movement mechanism this
is essential to restrict upper seat
recline movement to prevent
interference with lower seat.
Insert seat arms into upper
“Blossom” converter frame
sockets and push down rmly to
engage.
Depress the central grey buttons
and rotate into the desired
position.
Recline is restricted to
2 position to prevent interference
between upper and lower seats.
Remove child
rst. Depress lower portion of
the grey outer ring on each side
of seat unit, the frame will “Jump
up”. The rings can be depressed
simultaneously or independently.
10
11
12
13
