ICCONS™ GAS TOOL GT-3 & GT-3ST USER MANUAL
POS. CODE DESCRIPTION
Thread lock
POS. CODE DESCRIPTION
Thread lock
1 NB1010 PIN GUIDE 56 NB1600 AIR DAM
2 NB1390 GUIDE SLEEVE 57 NB1590 U-WIRE
3 NB140B Spring Dial 60 NB1610 HEAD O-RING
4 NB142A REAR SLEEVE 61 NB1620 BLADE ASSEMBLY Red 271
5 NB1410 NOSE PIECE 62 NB1630 CYLINDER HEAD
10 NB1040 SOCKET SCREW Blue 242 63 NB1650 SPARK PLUG
11 NB1050 BUSHING 64 NB1660 FUEL NOZZLE
12 NB1120 DUST SHIELD 65 NB1670 MOTOR SLEEVE
13 NB1070 SHIELD SPACER 66 NB1680 MOTOR BUMPER
14 NB1Z10 HOUSING 67 NB1690 MOTOR
15 NB1Z20 HEAD COVER 68 NB1700 MOTOR GUIDE
16 NB1780 SOCKET SCREW 69 NB1640 CONNECTOR BOARD
20 NB1Z30 HANDLE 70 NB1710 MOTOR HOLDER
21 NB1130 FIRING CAM 71 NB1720 SPRING WASHER
22 NB1Z40 FUEL DOOR 72 NB1730 ROUND HEAD SCREW
23 NB1Z50 BUSHING 80 NB179L TRACK (long)
24 NB1110 METAL WASHER 80 NB179S TRACK ST (short)
25 NB1100 SOCKET SCREW Blue 242 81 NB1ZA0 FOLLOWER
26 NB1290 METAL WASHER 82 NB1910 TRACK CAP
27 NB1170 LOCKNUT 83 NB1800 TRACK CONNECTOR
28 NB1380 METAL WASHER 84 NB1160 SOCKET SCREW
29 NB1370 SOCKET SCREW 85 NB1810 TRACK NUT
30 NB1Z60 CONTROL UNIT 86 NB1820 SOCKET SCREW Blue 242
31 NB1180 ELECTRODE ASSEMBLY 90 NB1140 HOOK & TRACK LOCK
32 NB1220 TRIGGER SWITCH
33 NB1310 MOTOR SWITCH # SCREW
34 NB1270 SELF TAP SCREW 10 M5 x 25 Blue 242
35 NB1Z70 TRIGGER 16 M5 x 30
36 NB1200 TRIGGER SPRING 25 M5 x 14 Blue 242
37 NB1300 SWITCH LEVER 29 M4 x 16
38 NB1260 SWITCH PLATE 34 Z3 x 10
39 NB1Z80 BATTERY LOCK 54 M5 x 6 Blue 242
40 NB1430 CAGE 72 M4 x 20
41 NB1440 CAGE SPRING 84 M4 x 8
42 NB1450 RETAINING RING 86 M5 x 8 Blue 242
43 NB1470 WAVE WASHER 92 Z4 x 10
44 NB1480 FLAT WASHER 95 Z4 x 20
45 NB1Z90 CYLINDER ASSEMBLY # NUT
46 NB1520 CYLINDER O-RING 27 M4
50 NB1530 BUMPER 85 M5
51 NB1540 PISTON ASSEMBLY # WASHER
52 NB1550 PISTON RING 24 12mm
53 NB1560 RETAINING RING 26 10mm
54 NB1570 SOCKET SCREW Blue 242 28 9mm
55 NB1580 COMBUSTION CHAMBER 71 M4
