The above pages are given for 3 phase 4 wire LT meters. For HT
meters, the resolution and units will change as given in technical
specifications. The display pages sequence and parameters can be
altered based on user requirement (to be mention while ordering).
0.863 LG 49.56 Hz
362.9 kVAr (H)
 
R 120.4 Y 121.8
B 120.6 kVAr (H)
0.866 LG 0.862 LG
0.864 LG (H)
Average PF, 3 Phase Individual kVAr 3 Phase Individual PF
Input Frequency
and Total kVAr
More key
More key
Page 5 :
792.1 kVAh
(or) 583.4 kWh(H)

P 1576.1 kVAh
(or) 123.3 kWh(H)
Total kVAh Previous kVAh
(or) kWh (or) kWh
More key
Page 6 :

More key
PT : RYB CTR : NIL
0:00 RH (H)
PT sequence,CT reversal PT sequence,CT reversal
and Runhour and Previous Runhour
PT : RYB CTR : NIL
0:00 PRH (H)
Page 7 :
User can select either
kVAh or kWh




