ICD MFM 9012 - 3-Phase 3-Wire HT System Wiring

7
3.2) Three phase three wire HT systems (2 watt measurement)
Voltage Input : 110V AC (L - L)(Through PT)
Current Input : 5/1A provide through 2 CT’s
D+
D-
Earth
Panel
Ground
To Load
CT’s
R
Y
B

Import


CT
Shorting
block
M L M L R Y B
I
R
I
B
RS 485
L N
(90 - 270V AC/DC)
Auxiliary
