37
Fastener Uses Kex Key (mm) nm lb-ft
Headrest clamp pin 5 5-7 4-5
Disc rotor bolts T-25 6-7 4.5-6
Master Cylinder Clamp Screw T-10 1.7-2.3
Caliper Bleed Screw 8mm Spanner 3-5 2.5-4
Caliper Mounting Bolts 5 11-13 8-10
All other M4 bolts, tighten to 5-6 nm
(4-5 lb-ft)
All other M5 bolts, tighten to 6-8 nm
(4.5-6 lb-ft)
All other M6 bolts, tighten to 8-10 nm (6-7 lb-ft)
