Ice iW90 User Manual

ICE iW90 11
OPERATOR
PARTS LIST
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 2320500 Hose Assy 1
2 2230121 Machine End 1
3 2320501 Threaded Insert 2
4 2230123 Clip Ring 2
5 2320502 Hose 1
6 2230124 Angeled Hose End, 38mm 1
7 2320208 Acoustic Insulstion Pipe 1
8 1914300 Tie, Cable 1
9 1221616 Screw, Ph, M6 X16 5
10 2320214 Leaf Spring 1
11 2320304 Knob, Floor Tool 1
12
2320311 26" Blade(PU) 2
2320309 26" Blade(Optional) 2
13 1221514 Screw, Ph, M5 X14 4
14 2320303 Clamp, Blade 1
15 1321310 Screw, Ph, St4.8 X10 2
16 1421618 Washer,Plain,
Φ
6.4X
Φ
18X1.6 4
17 1021825 Screw,Hex, M8 X25 2
18 1439005 Retaining Ring,
Φ
5 4
19 2320308 2" Wheel 2
20 2320306 Axle, 2" Wheel 2
21 2320302 Bumper 2
22 2320301 26" Body,Pick-Up Tool 1
23 2320215 Mounting Plate, Floor Tool 1
24 2320212 Axle, Mounting Plate 1
25 1421020 Washer,Plain,
Φ
10.5X
Φ
20X2 6
26 1436010 Retaining Ring,
Φ
10 6
27 2320213 Axle, Pedal 2
28 2320209 Pedal 1
29 2320411 Strain Relief 1
30 2320203 Bottom Plate, Assy 1
31 1422616
Washer, Lock,
Φ
6
5
32 2310123 Filter 1
33 2310118 Gasket 2
34 1123608 Nut, Lock, M6 3
35 1421617 Washer,Plain,
Φ
6.2X
Φ
16X2 11
36
2310121A Vac Motor,3-Stg,120V,With Terminal,
Serial number:000000-000592 1
8011025A Vac Motor,2-Stg,120V,With Terminal,Serial number:000593- 1
37
2310122 Stud,Vac Motor 3-Stg,
Serial number:000000-000592 3
8112006 Stud,Vac Motor 2-Stg,Serial number:000593- 3
38 1121605 Nut, M6 3
39 2310116 Gasket,Vac Motor 1
40 2310120 Screen 1
41 2320308A 2" Wheel Assy 2
