iCEBOX PFU-45-067 User Manual

Air flow rate
l/s 300 380 530 750 1100 1300
Ext static pressure
Pa 250 250 250 250 250 250
Cooling
Coil rows
# 6 6 6 6 6 6
Fin/in
# 12 12 12 12 12 12
Face vel
m/s 2.2 2.2 2.2 2.2 2.2 2.2
On coil temp (°c)
DB 25.0 25.0 25.0 25.0 25.0 25.0
WB 18.0 18.0 18.0 18.0 18.0 18.0
Off coil temp (°c)
DB 10.9 10.4 10.5 10.4 10.8 10.4
WB 10.6 10.2 10.2 10.1 10.5 10.1
Capacity (kw)
TOTAL 7.2 9.6 13.3 19.0 26.9 33.1
SENSIBLE 4.8 6.4 8.8 12.6 17.9 21.8
Water in
°C 6.0 6.0 6.0 6.0 6.0 6.0
Water out
°C 12.0 12.0 12.0 12.0 12.0 12.0
Water flow
l/s 0.29 0.38 0.53 0.76 1.07 1.31
Water speed
m/s 0.76 1.01 0.93 1 0.8 1
Water pd
kPa 30 29 29 25 16 26
Pipe conn
BSP 1/2 1 1 1 1-1/4 1-1/4
Heating
Coil row
# 1 1 1 1 1 1
On coil temp (°c)
DB 20.0 20.0 20.0 20.0 20.0 20.0
Off coil temp (°c)
DB 33.2 33.6 34.1 34.1 34.4 33.7
Capacity (kw)
TOTAL 4.8 6.3 9.2 12.9 19.5 21.9
Water in
°C 80 80 80 80 80 80
Water out
°C 60 60 60 60 60 60
Water flow
l/s 0.06 0.08 0.11 0.16 0.24 0.27
Water pd
kPa 2 4 11 11 30 19
Pipe conn
BSP 1/2 1/2 1/2 1/2 1/2 1/2
Fan
Fan speed contrl
# EC EC EC EC EC EC
Drive type
# DD PLUG DD PLUG DD PLUG DD PLUG DD PLUG DD PLUG
Fan+mtr qty
# 1 1 1 2 2 2
Fan model
# 280 280 280 2x280 2x280 2x280
Motor power
W 500 500 500 2x500 2x500 2x500
Power rating
V/Ph/Hz 220-1-50 220-1-50 220-1-50 220-1-50 220-1-50 220-1-50
Dimensional
Model
25mm
PU PANEL
CASING
PFU-45-067 PFU-45-079 PFU-45-102 PFU-45-135 PFU-50-163 PFU-50-191
Weight (kg)
75 83 98 129 156 173
Dimension(mm) h-w-l
450-670-800 450-790-800 450-1020-800 450-1350-800 500-1630-800 500-1910-800
Model
50mm
PU PANEL
CASING
PBU-50-073 PBU-50-084 PBU-50-107 PBU-50-140 PBU-55-168 PBU-55-196
Weight (kg)
88 97 114 148 178 198
Dimension(mm) h-w-l
500-730-800 500-840-800 500-1070-800 500-1400-800 550-1680-800 550-1960-800
6 ROW TECHNICAL PERFORMANCE
ICEBOX FAN COIL UNITS IOM | 15
