7 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC601 1110002751 S.IC TA75S01F (TE85R,F) T 24.4/23.1
Q602 1560001241 S.FET RD01MUS1-T113 B 3.5/13.2
Q603 1530003421 S.TR 2SC5110-O (TE85R,F) B 8/18.1
Q604 1590002160 S.TR XP6401-(TX) T 7.7/15.3
Q605 1530002060 S.TR 2SC4081 T106 R T 8/17.9
Q606 1590003290 S.TR UNR9213J-(TX) T 21/20.5
D601 1750000581 S.DIO 1SV307 (TPH3,F) T 22.4/10
D603 1750000581 S.DIO 1SV307 (TPH3,F) B 17.8/13.2
D604 1790001670 S.DIO RB706F-40T106 T 17.4/6.1
D605 1790001670 S.DIO RB706F-40T106 B 28.4/21.7
D606 1790001250 S.DIO MA2S111-(TX) T 29.8/21.7
D607 1730002430 S.ZEN MA8150-M (TX)
except [USA-01], [GEN-01] T 17.2/21.4
L601 6200012780 S.COL 0.30-1.4-6TL 27.2N B 30.8/9.2
L602 6200012470 S.COL 0.30-1.7-7TL 45.3N B 30.2/12.4
L603 6200012910 S.COL 0.35-1.6-8TL 45.5N B 27.3/15.7
L604 6200012470 S.COL 0.30-1.7-7TL 45.3N B 20.1/13.1
L605 6200002861 S.COL NLV25T-4R7J T 25.2/11.1
L606 6200012780 S.COL 0.30-1.4-6TL 27.2N B 20.5/4.4
L607 6200012390 S.COL 0.30-0.92-3TR 5.8N B 16/4.1
L608 6200012400 S.COL 0.30-0.91-4TL 8.6N B 12.6/5.6
L609 6200012960 S.COL 0.45-1.4-4TL 12.1N B 9.2/11.8
L610 6200005711 S.COL ELJRE 27NGFA B 6.7/13.8
L611 6200003590 S.COL EXCCL3225U1 B 14.6/17.4
L612 6200005731 S.COL ELJRE 39NGFA B 4.6/18.6
L613 6200006190 S.COL BLM21PG300SN1D T 13.1/20.2
R601 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 29/8.3
R603 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 18/3.3
R604 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 17.7/9
R605 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 17.7/10
R606 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 27.6/20.4
R607 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 19.4/20.9
R608 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 26.6/22
R609 7030005530 S.RES ERJ2GEJ 100 X (10) B 24.1/24.7
R610 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 28.6/22
R611 7030004990 S.RES ERJ2GEJ 221 X (220) T 29.4/20
R613 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 4.2/7.4
R614 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 2.4/8.6
R615 7030007250 S.RES ERJ2GEJ 220 X (22) B 4/8.6
R616 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 3.4/17.4
R617 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 2.4/18.4
R618 7030004980 S.RES ERJ2GEJ 101 X (100) B 3.8/16.2
R619 7030004980 S.RES ERJ2GEJ 101 X (100) B 6/17.7
R620 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 7.7/21.2
R621 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 6.7/20
R622 7030005530 S.RES ERJ2GEJ 100 X (10) T 6.8/21.4
R623 7030007330 S.RES ERJ1WRSJR15U (0.15) T 16/16.8
R624 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 12.9/14.4
R625 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 6/18.1
R626 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 7.7/20.2
R627 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 6.7/20.2
R628 7030003370 S.RES ERJ3GEYJ 271 V (270) T 26.7/17
R629 7030003370 S.RES ERJ3GEYJ 271 V (270) T 25.4/17
R631 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 21.7/18.7
R632 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 28.7/19.2
R633 7030007340 S.RES ERJ2GEJ 153 X (15 k)
except [USA-01], [GEN-01] B 26.5/20.8
C601 4030006990 S.CER C1608 CH 1H 080D-T B 30.6/6.4
C602 4030011770 S.CER C1608 CH 1H 060B-T B 33.1/10.5
C604 4030009650 S.CER C1608 CH 1H 240J-T B 28.5/7.7
C605 4030009920 S.CER C1608 CH 1H 050B-T B 32.3/13.1
C606 4030007060 S.CER C1608 CH 1H 270J-T B 28.1/11.7
C608 4030009540 S.CER C1608 CH 1H 1R5B-T B 27.7/17.8
C609 4030007020 S.CER C1608 CH 1H 120J-T B 25.5/11.7
C610 4030017460 S.CER ECJ0EB1E102K B 24.1/12.1
C611 4030007020 S.CER C1608 CH 1H 120J-T B 23.4/10.3
C612 4030017650 S.CER ECJ0EC1H270J B 21.1/15.5
C613 4030017460 S.CER ECJ0EB1E102K T 25.8/13.3
C614 4030017460 S.CER ECJ0EB1E102K T 25.3/19.2
C615 4030017460 S.CER ECJ0EB1E102K T 21/7.8
C616 4030007040 S.CER C1608 CH 1H 180J-T B 20.9/8
C617 4030007040 S.CER C1608 CH 1H 180J-T B 19.6/8
C618 4030017530 S.CER ECJ0EC1H0R5B T 17.4/3.8
C619 4030017460 S.CER ECJ0EB1E102K T 17.7/8
C620 4030017460 S.CER ECJ0EB1E102K B 19.3/6.3
C622 4030011770 S.CER C1608 CH 1H 060B-T B 18.3/8
C623 4030007100 S.CER C1608 CH 1H 560J-T B 17.9/5.4
C624 4030007110 S.CER C1608 CH 1H 680J-T B 14.5/6.5
C626 4030017460 S.CER ECJ0EB1E102K T 28.2/17.5
C627 4030016790 S.CER ECJ0EB1C103K T 21.8/22.3
C628 4030016930 S.CER ECJ0EB1A104K except [Europe] T 27.6/22
4030016940 S.CER ECJ0EB1A393K [Europe] T 27.6/22
C629 4030017460 S.CER ECJ0EB1E102K B 25.8/18.8
C630 4030016930 S.CER ECJ0EB1A104K T 24.5/25.3
C631 4030017460 S.CER ECJ0EB1E102K T 28.6/18.7
C632 4030017460 S.CER ECJ0EB1E102K B 21/20.2
C633 4030017460 S.CER ECJ0EB1E102K B 13.7/15.4
C634 4030017460 S.CER ECJ0EB1E102K B 2.2/7.4
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C635 4030017730 S.CER ECJ0EB1E471K B 3.2/7.4
C637 4030017460 S.CER ECJ0EB1E102K T 3.1/9.3
C638 4030017430 S.CER ECJ0EC1H101J B 4.7/9.8
C639 4030017490 S.CER C1608 JB 1A 105K-T B 13.8/14.2
C640 4030017460 S.CER ECJ0EB1E102K B 8.1/14.7
C642 4030016790 S.CER ECJ0EB1C103K B 2.2/16.2
C643 4030017460 S.CER ECJ0EB1E102K B 2.2/17.2
C644 4030017420 S.CER ECJ0EC1H470J T 2/18.8
C645 4030017460 S.CER ECJ0EB1E102K T 4.2/18.8
C646 4030017430 S.CER ECJ0EC1H101J B 5/16.5
C647 4030017420 S.CER ECJ0EC1H470J T 5.6/21.5
C648 4030017460 S.CER ECJ0EB1E102K B 5.7/21.5
C649 4030017460 S.CER ECJ0EB1E102K T 10.1/22.8
C650 4030017460 S.CER ECJ0EB1E102K B 6/18.7
C651 4030017650 S.CER ECJ0EC1H270J B 8.3/20
C653 4030017460 S.CER ECJ0EB1E102K T 17.2/14.2
C654 4030017460 S.CER ECJ0EB1E102K T 6/17.1
C655 4030017460 S.CER ECJ0EB1E102K T 8.7/20.2
C656 4030016930 S.CER ECJ0EB1A104K T 16.5/19.4
C657 4030017460 S.CER ECJ0EB1E102K T 15.5/19.4
C658 4030017420 S.CER ECJ0EC1H470J T 14.5/19.4
C659 4030017420 S.CER ECJ0EC1H470J T 14.7/21.2
C660 4030017460 S.CER ECJ0EB1E102K T 13.2/23.8
C661 4030016930 S.CER ECJ0EB1A104K T 12.2/23.8
C662 4030017460 S.CER ECJ0EB1E102K B 6.8/11.2
C663 4030009920 S.CER C1608 CH 1H 050B-T B 34.3/10.5
C664 4030011770 S.CER C1608 CH 1H 060B-T B 15.7/6.5
C665 4030017530 S.CER ECJ0EC1H0R5B B 29.8/20.1
C666 4030017460 S.CER ECJ0EB1E102K B 26.5/22.4
C667 4030018910 S.CER C1608 JB 0J 475K-T [Europe] only B 23.5/22.3
J601 6910017940 CNR IMSA-9230B-1-05Z118-PT1
J602 6910017940 CNR IMSA-9230B-1-05Z118-PT1
F601 5210000970 S.FUS ERBSE3R00U T 13.9/22.4
EP602 6910012350 S.BEA MMZ1608Y 102BT B 7.8/15.8
[VR UNIT] (
except [FRG-01])
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q701 1590001400 S.TR XP1214 (TX) T 32.2/6.2
R701 7410001140 S.ARY EXB28V104JX T 11.4/1.8
R702 7030007280 S.RES ERJ2GEJ 331 X (330) T 31.7/8.6
R703 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 32.7/8.6
R704 7210003061 VAR TP76N00N-15F-A103-2251A
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.2/2.8
C701 4030017420 S.CER ECJ0EC1H470J T 10.1/5.2
C702 4030017420 S.CER ECJ0EC1H470J T 11.1/5.2
C703 4030017420 S.CER ECJ0EC1H470J T 12.1/5.2
C704 4030017420 S.CER ECJ0EC1H470J T 14.3/3.2
J701 6510024930 S.CNR 20RF-JMCSG1BTF B 11.4/4.1
DS701 5040002670 S.LED CL-165HR/YG T 33.5/11.1
S701 2250000490 ECR TP70TF5163-15.9F-2775
S702 2230001060 S.SW EVQ-PUL 02K T 8/10.4
[VR-A UNIT] (
[FRG-01])
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q701 1590001400 S.TR XP1214 (TX) T 32.2/6.2
R701 7410001140 S.ARY EXB28V104JX T 11.2/1.8
R702 7030007280 S.RES ERJ2GEJ 331 X (330) T 31.7/8.6
R703 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 32.7/8.6
R704 7210003061 VAR TP76N00N-15F-A103-2251A
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.1/2.9
C701 4030017420 S.CER ECJ0EC1H470J T 10.1/5.2
C702 4030017420 S.CER ECJ0EC1H470J T 11.1/5.2
C703 4030017420 S.CER ECJ0EC1H470J T 12.1/5.2
C704 4030017420 S.CER ECJ0EC1H470J T 14/3.9
J701 6510024930 S.CNR 20RF-JMCSG1BTF B 11.4/4.1
DS701 5040002670 S.LED CL-165HR/YG T 33.5/11.1
