Icom IC-F3062T Servise Manual

7 - 8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT] (for F3160 series)
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R90 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 70.4/26.4
R91 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 66/27.9
R95 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 87.2/36.6
R95 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 87.2/36.6
R99 7030004980 S.RES ERJ2GEJ 101 X (100) B 88.4/37.5
R100 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 83/33.1
R101 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 81.4/35.2
R101 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 81.4/35.2
R102 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 75.4/29.6
R103 7030004970 S.RES ERJ2GEJ 470 X (47) B 81.4/36.1
R104 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 70.5/35.6
R105 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 69.1/34.4
R106 7030010040 S.RES ERJ2GEJ-JPW T 70.3/36.8
R107 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 71.4/37.9
R108 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 72.3/35.2
R109 7030007060 S.RES ERJ2GEJ 684X (680 k) B 67.1/30.5
R110 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 69.1/33.6
R111 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 69.1/41
R112 7030005000 S.RES ERJ2GEJ 471 X (470) B 79.3/36.6
R113 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 48.3/17.3
R115 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 92.1/19
R116 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 91/20.3
R117 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 88/22.4
R118 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 93.6/33.5
R119 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 91.9/33
R120 7030005600 S.RES ERJ2GEJ 273 X (27 k) B 90.8/36
R121 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 72.3/35
R122 7030005000 S.RES ERJ2GEJ 471 X (470) B 74.1/38.2
R122 7030005710 S.RES ERJ2GEJ 121 X (120) B 74.1/38.2
R123 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 73.2/36.6
R123 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 73.2/36.6
R124 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 73.2/38.2
R124 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 73.2/38.2
R126 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 37.1/29.5
R127 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 38/31.1
R128 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 46.4/34.5
R130 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) B 62.2/36.3
R131 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 64.6/37.6
R132 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 63/37.6
R133 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 64.4/33.9
R134 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 65.3/33.9
R135 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 63.5/33.9
R136 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 61.3/34.1
R137 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 66.1/36.6
R138 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 67.1/38.2
R139 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 67.1/36.6
R140 7030011660 S.RES ERJ2RKF 1002 (10 k) B 57.3/39.6
R141 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 57.3/41.2
R142 7030011660 S.RES ERJ2RKF 1002 (10 k) B 56.4/38
R143 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 54.4/38.3
R144 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 45.9/38
R145 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 47.5/31.1
R146 7030010040 S.RES ERJ2GEJ-JPW T 44.3/29.6
R147 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 55.6/40.2
R148 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 55.6/39.3
R149 7030010040 S.RES ERJ2GEJ-JPW T 56.2/37.9
R150 7030005530 S.RES ERJ2GEJ 100 X (10) B 34.1/7.5
R151 7030004980 S.RES ERJ2GEJ 101 X (100) T 45.6/19.3
R152 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 46.4/36.8
R153 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 46.7/35.2
R154 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 45.1/36.2
R155 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 45.3/5.6
R156 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 52.4/6.2
R156 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 52.4/6.2
R157 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 54.3/9.7
R158 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 45.2/39.8
R159 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.2/38.9
R161 7030010040 S.RES ERJ2GEJ-JPW B 38/29.5
R162 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 53.4/9.1
R163 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.3/19.3
R164 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 38.4/19.3
R165 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) B 41.6/23.9
R165 7030010040 S.RES ERJ2GEJ-JPW B 41.6/23.9
R167 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 36.1/5.8
R168 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 49.1/29.9
R169 7030011650 S.RES ERJ2GEJ 243X (24 k) B 46.9/31.4
R170 7030004980 S.RES ERJ2GEJ 101 X (100) T 52.8/25.9
R171 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 55.2/20.5
R174 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 49.6/25.9
R175 7030007280 S.RES ERJ2GEJ 331 X (330) T 51.2/25.9
R176 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 37.7/9.1
R177 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 53.4/10.7
R178 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 37.7/30.6
R179 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 40.6/29.5
R180 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 39.3/31.5
R181 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 39.3/29.7
R181 7030011680 S.RES ERJ2RKF 2703 (270 k) T 39.3/29.7
R182 7030010040 S.RES ERJ2GEJ-JPW B 41.7/25.4
R183 7030007060 S.RES ERJ2GEJ 684X (680 k) B 46.9/27.4
R184 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 47.8/28.6
R185 7030005230 S.RES ERJ2GEJ 334 X (330 k) B 47.8/29.8
R186 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 47.8/26.2
R189 7030010040 S.RES ERJ2GEJ-JPW B 91.5/7.3
R190 7030005700 S.RES ERJ2GEJ 274 X (270 k) B 99.8/11.2
R191 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 99/9.1
R192 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 102.2/9.2
R193 7030004980 S.RES ERJ2GEJ 101 X (100) T 99.5/6.2
R194 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 96.8/7.3
R195 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 95.3/6.9
R196 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 93.8/9.3
R197 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 90.7/11.4
R198 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 88.7/10.8
R199 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 91.6/10.5
R200 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 91.4/9.1
S.=Surface mount
[MAIN-A UNIT] (for F3160 series)
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R201 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 62.5/11.4
R202 7030005110 S.RES ERJ2GEJ 224 X (220 k) B 70.2/21.5
R203 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 64.4/28.8
R204 7030008370 S.RES ERJ2GEJ 561 X (560) T 59.6/29.5
R205 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 59.3/30.7
R206 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 28.3/33.8
R207 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 32.1/36.1
R208 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 25.9/32.5
R209 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 25/33.4
R210 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 24.1/33.4
R211 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 10.7/20.6
R212 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 22.1/36.4
R213 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 21.5/38
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 22.4/41.3
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 20.5/39.2
R216 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 20.6/37.3
R217 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 41.7/26.3
R219 7030004980 S.RES ERJ2GEJ 101 X (100) T 17.8/29.4
R220 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 40.1/26.3
R221 7410001130 S.ARY EXB28V102JX B 30.5/27
R222 7410001130 S.ARY EXB28V102JX B 24.6/13
R223 7410001130 S.ARY EXB28V102JX T 16.2/22.9
R225 7410001130 S.ARY EXB28V102JX B 28.7/17.6
R226 7410001130 S.ARY EXB28V102JX B 21/13.6
R227 7410001130 S.ARY EXB28V102JX B 32.4/25.1
R228 7030005000 S.RES ERJ2GEJ 471 X (470) T 103.3/33.9
R229 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 31/8.6
R230 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 31/6.8
R231 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 102.4/35.6
R235 7410001130 S.ARY EXB28V102JX B 19/15.6
R238 7030004980 S.RES ERJ2GEJ 101 X (100) B 12.7/21.7
R239 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.3/27.1
R240 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 26.8/10.2
R242 7410001130 S.ARY EXB28V102JX T 21.5/19.1
R243 7030005530 S.RES ERJ2GEJ 100 X (10) T 7.7/28.7
R244 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 6.5/29.1
R245 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 15.8/32.2
R246 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 10.8/31.4
R247 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 10.8/29.6
R248 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 24.8/25.1
R249 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 24.8/26
R251 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 27.5/32.2
R252 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 31.7/29.8
R253 7410001140 S.ARY EXB28V104JX T 27.9/28.4
R255 7410001130 S.ARY EXB28V102JX B 28.5/29
R257 7410001130 S.ARY EXB28V102JX T 25.5/31.8
R258 7410001140 S.ARY EXB28V104JX T 32.5/29.8
R259 7410001130 S.ARY EXB28V102JX B 19.8/32.2
R260 7030010040 S.RES ERJ2GEJ-JPW B 29.8/36.4
R261 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 23.8/34.7
R262 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 22.6/29.9
R263 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 24.2/29.9
R264 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 24.7/28.7
R265 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 23.8/28.7
R266 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 22.2/34.7
R267 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 12.9/19.3
R268 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 12.7/20.6
R272 7030004970 S.RES ERJ2GEJ 470 X (47) T 90/18.9
R273 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 88.7/14.2
R274 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 89.4/17.4
R275 7030004980 S.RES ERJ2GEJ 101 X (100) B 90.3/15.6
R276 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.1/23.8
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 10.3/23.4
R279 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.3/30
R280 7510001730 S.TMR ERTJOEP 473J B 57.5/8.5
R281 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 56.8/7.6
R282 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 71.4/21.6
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 35.9/16.1
R283 7030008300 S.RES ERJ2GEJ 184 X (180 k) B 35.9/16.1
R284 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 62.5/27.9
R286 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 64.4/29.7
R287 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28.8/40.8
R288 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 27.9/40.8
R289 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 35.3/41.7
R289 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 35.3/41.7
R290 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 28.9/41
R291 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 45.5/24.4
R292 7030005530 S.RES ERJ2GEJ 100 X (10) B 88.7/33.3
R293 7030007270 S.RES ERJ2GEJ 151 X (150) B 93.3/21.3
R294 7030007280 S.RES ERJ2GEJ 331 X (330) B 91.4/32.8
R295 7030005710 S.RES ERJ2GEJ 121 X (120) T 89.9/22.5
R296 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 92.8/15.7
R297 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 91.5/13.9
R298 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 91.3/15.1
R300 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 90.3/14.2
R302 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.7/11.9
R305 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 42.2/13.9
R306 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 20/25.5
R308 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 7.8/31.6
R309 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 45.9/13.1
R310 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.1/36.5
R311 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 15/27.1
R312 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 22.3/10.8
R313 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 8.2/33
R314 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 9.6/32.3
R315 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 11.3/31.7
R316 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 6.5/29.7
R317 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 14.3/24.7
R318 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 10.8/12.7
R319 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 10.6/15.8
R321 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 88.6/20.8
R322 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 87.6/20.6
R323 7030007280 S.RES ERJ2GEJ 331 X (330) T 87.9/24.3
R325 7030007270 S.RES ERJ2GEJ 151 X (150) B 92.1/21.7

Icom IC-F3062T Specifications

General

Brand	Icom
Model	IC-F3062T
Category	Transceiver
Language	English
