Icom IC-FR3100 Service Manual

[RX UNIT][RX UNIT]
C137 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C138 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C140 4510004640
S.ELECTROLYTIC ECEV1CA470SP T
C141 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C142 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C143 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C146 4510004630
S.ELECTROLYTIC ECEV1CA100SR T
C151 4030007010 S.CERAMIC C1608 CH 1H 100D-T B
C152 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C153 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C158 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C159 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C165 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C166 4030008880 S.CERAMIC C1608 JB 1H 223K-T B
C167 4550002980 S.TANTALUM TEESVA 1C 225M8L B
C173 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C175 4550006350 S.TANTALUM TEESVB2 1A 226M8L B
C177 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C180 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C181 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C182 4030011770 S.CERAMIC C1608 CH 1H 060B-T T
C183 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C184 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C186 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C187 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C188 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C191 4030007010 S.CERAMIC C1608 CH 1H 100D-T [FR4000] T
4030007030 S.CERAMIC C1608 CH 1H 150J-T [FR4100] T
C192 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C193 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C194 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C195 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C196 4550000530 S.TANTALUM TEESVA 1V 104M8L B
C199 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C200 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C201 4550006250 S.TANTALUM TEESVA 1A 106M8L B
C202 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C203 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C204 4550006250 S.TANTALUM TEESVA 1A 106M8L B
C205 4030006980 S.CERAMIC C1608 CH 1H 070D-T
[GEN2], [GEN6], [EUR3], [FRG3] T
4030009910 S.CERAMIC C1608 CH 1H 040B-T
[USA3], [GEN3], [GEN7] T
4030011770 S.CERAMIC C1608 CH 1H 060B-T Other T
C206 4030006980 S.CERAMIC C1608 CH 1H 070D-T
[GEN2], [GEN6], [EUR3], [FRG3] T
4030009910 S.CERAMIC C1608 CH 1H 040B-T
[USA3], [GEN3], [GEN7] T
4030011770 S.CERAMIC C1608 CH 1H 060B-T Other T
C207 4030007030 S.CERAMIC C1608 CH 1H 150J-T Other T
4030007040 S.CERAMIC C1608 CH 1H 180J-T
[GEN2], [GEN6] T
4030009910 S.CERAMIC C1608 CH 1H 040B-T
[USA3], [GEN3], [GEN7] T
4030009920 S.CERAMIC C1608 CH 1H 050B-T
[EUR3], [FRG3] T
C208 4030007030 S.CERAMIC C1608 CH 1H 150J-T Other T
4030007040 S.CERAMIC C1608 CH 1H 180J-T
[GEN2], [GEN6] T
4030009910 S.CERAMIC C1608 CH 1H 040B-T
[USA3], [GEN3], [GEN7] T
4030009920 S.CERAMIC C1608 CH 1H 050B-T
[EUR3], [FRG3] T
C210 4030006980 S.CERAMIC C1608 CH 1H 070D-T [H] T
4030007000 S.CERAMIC C1608 CH 1H 090D-T [L], [M] T
C211 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C212 4030007170 S.CERAMIC C1608 CH 1H 221J-T T
C213 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C214 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C215 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C216 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C217 4030007020 S.CERAMIC C1608 CH 1H 120J-T B
C220 4030008650 S.CERAMIC C1608 JB 1H 332K-T T
C221 4030006980 S.CERAMIC C1608 CH 1H 070D-T
[GEN2], [GEN6], [EUR3], [FRG3] T
C222 4030006980 S.CERAMIC C1608 CH 1H 070D-T
[GEN2], [GEN6], [EUR3], [FRG3] T
C223 4030007020 S.CERAMIC C1608 CH 1H 120J-T
[GEN2], [GEN6] T
4030007040 S.CERAMIC C1608 CH 1H 180J-T [L] T
4030009920 S.CERAMIC C1608 CH 1H 050B-T
[EUR3], [FRG3] T
C224 4030007020 S.CERAMIC C1608 CH 1H 120J-T
[GEN2], [GEN6] T
4030007040 S.CERAMIC C1608 CH 1H 180J-T [L] T
4030009920 S.CERAMIC C1608 CH 1H 050B-T
[EUR3], [FRG3] T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
C225 4030006860 S.CERAMIC C1608 JB 1H 102K-T
[EUR3], [FRG3] T
4030009530 S.CERAMIC C1608 CH 1H 030B-T [L], [M] T
C227 4030009920 S.CERAMIC C1608 CH 1H 050B-T
[GEN2], [GEN6], [EUR3], [FRG3] only T
C228 4030006980 S.CERAMIC C1608 CH 1H 070D-T
[GEN2], [GEN6] only T
C230 4030007170 S.CERAMIC C1608 CH 1H 221J-T
[EUR1], [FRG1] only T
C231 4030007170 S.CERAMIC C1608 CH 1H 221J-T [L] only T
C232 4030007170 S.CERAMIC C1608 CH 1H 221J-T
[EUR1], [FRG1] only T
J1 6510018450 CONNECTOR TMP-S01X-B1 T
J2 6510022590 S.CONNECTOR 22FMN-BMTTR-A-TBT T
J5 6510018450 CONNECTOR TMP-S01X-B1 T
W1 7030003860 S.RESISTOR ERJ3GE JPW V B
W2 7030003860 S.RESISTOR ERJ3GE JPW V B
W3 7030003860 S.RESISTOR ERJ3GE JPW V B
W4 7030003860 S.RESISTOR ERJ3GE JPW V B
W6 7030003860 S.RESISTOR ERJ3GE JPW V B
W7 7030003860 S.RESISTOR ERJ3GE JPW V T
W8 7030003860 S.RESISTOR ERJ3GE JPW V T
W12 7030003860 S.RESISTOR ERJ3GE JPW V T
W13 7030003860 S.RESISTOR ERJ3GE JPW V T
W14 7030003860 S.RESISTOR ERJ3GE JPW V T
W15 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only T
W16 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only T
W17 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only T
W18 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only T
W19 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only B
W20 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only B
W21 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only B
W22 7030003860 S.RESISTOR ERJ3GE JPW V [M], [H] only B
W23 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] T
W24 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] T
W25 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] T
W26 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] T
W27 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] B
W28 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] B
W29 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] B
W30 7030003860 S.RESISTOR ERJ3GE JPW V
[L], [USA3], [GEN3], [GEN7] B
W31 7030003860 S.RESISTOR ERJ3GE JPW V
[USA3], [GEN3], [GEN7] B
W32 7030003860 S.RESISTOR ERJ3GE JPW V
[USA3], [GEN3], [GEN7] B
EP1 0910057001 PCB B 5657K
5 - 10
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
