Icom IC-FR3100 Service Manual

[TX UNIT][RVCO UNIT]
Q1 1560001280 S.FET 2SK508 K53 T1B T
Q2 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
D1 1720000640 S.VARICAP 1SV284 (TPH3) T
D2 1720000640 S.VARICAP 1SV284 (TPH3) T
D3 1720000640 S.VARICAP 1SV284 (TPH3) T
D4 1720000640 S.VARICAP 1SV284 (TPH3) T
L1 6200007120 S.COIL ELJND 1R0J T
L2 6200008730 S.COIL ELJND R10J T
L3 6200009700 S.COIL C6328A-28NG-A [L] T
6200010290 S.COIL C6328A-22NG-A [M], [H] T
L4 6200008730 S.COIL ELJND R10J T
L5 6200007210 S.COIL ELJND 10NKF T
L6 6200005700 S.COIL ELJRE 22NG-F T
L9 6200005740 S.COIL ELJRE 47NG-F T
R1 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R2 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R3 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R4 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R5 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω) T
R6 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R13 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C2 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C3 4550006770 S.TANTALUM TEESVD2 1C 476M-12R T
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C7 4030006980 S.CERAMIC C1608 CH 1H 070D-T T
C8 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C9 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C10 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T T
C11 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C13 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C14 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C17 4610001920 S.TRIMMER TZC3Z060A110R00 T
C22 4030009510 S.CERAMIC C1608 CH 1H 010B-T [H] T
4030009520 S.CERAMIC C1608 CH 1H 020B-T [L], [M] T
C27 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C28 4030009520 S.CERAMIC C1608 CH 1H 020B-T [L], [H] only T
J1 6510022900 CONNECTOR IMSA9201B-1-06Z198-T T
EP1 0910056144 PCB B 5658D
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
IC1 1180000420 S.IC TA78L05F (TE12R) B
IC2 1140005990 S.IC MB15A02PFV1-G-BND-ER B
IC3 1110002400 S.IC NJM2107F-TE1 B
IC4 1180000430 S.IC TA78L06F (TE12L) B
IC5 1190001350 S.IC M62364FP 600D B
IC6 1110002400 S.IC NJM2107F-TE1 T
Q1 1530000371 S.TRANSISTOR 2SC3356-T1B R25 T
Q2 1530003270 S.TRANSISTOR 2SC4703-T1 SF T
Q3 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q5 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R) T
Q6 1530002050 S.TRANSISTOR 2SC3661-TB B
Q7 1510000510 S.TRANSISTOR 2SA1576A T106R B
Q9 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R) B
Q10 1560000540 S.FET 2SK880-Y (TE85R) T
D1 1790001620 S.DIODE 1SV308 (TPL3) T
D3 1710000840 S.DIODE 1SR154-400 TE25 T
D4 1790001250 S.DIODE MA2S111-(TX) B
X1 6050011480 S.XTAL CR-732 (12.800 MHz) Other T
6050011680 S.XTAL CR-758 (12.8 MHz)
[USA1], [USA3], [FR4100] T
L1 6200007690 S.COIL LQW2BHN18NJ01L B
L2 6200007710 S.COIL LQW2BHN27NJ01L T
L3 6200007230 S.COIL LQW2BHN15NJ01L T
L8 6200008730 S.COIL ELJND R10J T
L9 6200008730 S.COIL ELJND R10J T
L10 6200007690 S.COIL LQW2BHN18NJ01L B
L11 6200007710 S.COIL LQW2BHN27NJ01L B
L14 6200007670 S.COIL LQW2BHN10NJ01L T
L15 6200007700 S.COIL LQW2BHN22NJ01L T
L16 6200007700 S.COIL LQW2BHN22NJ01L T
L17 6910011690 S.COIL ACB1608M-600-T B
L18 6910011690 S.COIL ACB1608M-600-T B
L19 6910011690 S.COIL ACB1608M-600-T B
L20 6910011690 S.COIL ACB1608M-600-T B
L21 6910011690 S.COIL ACB1608M-600-T B
L22 6910011690 S.COIL ACB1608M-600-T B
L23 6910011690 S.COIL ACB1608M-600-T B
L24 6910011690 S.COIL ACB1608M-600-T B
L25 6910011690 S.COIL ACB1608M-600-T B
L26 6910011690 S.COIL ACB1608M-600-T B
L27 6200009940 S.COIL BLM21PG221SN1 B
L28 6200009940 S.COIL BLM21PG221SN1 T
L29 6910011690 S.COIL ACB1608M-600-T T
L30 6910011690 S.COIL ACB1608M-600-T B
R1 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R2 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R3 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) B
R4 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R5 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R6 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) T
R7 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
[L], [M] only T
R8 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R9 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R10 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) T
R11 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω) T
R16 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R17 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω) T
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R19 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R20 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R21 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R23 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R24 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R25 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R26 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R27 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R29 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R31 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ) B
R33 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R37 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R38 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R39 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R41 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R45 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R50 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
5 - 11
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
