Icom IC-FR3100 Service Manual

[25PA UNIT] IC-FR4100 ONLY[TVCO UNIT]
Q1 1530000371 S.TRANSISTOR 2SC3356-T1B R25 T
Q2 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
D1 1720000640 S.VARICAP 1SV284 (TPH3) T
D2 1720000640 S.VARICAP 1SV284 (TPH3) T
D3 1720000640 S.VARICAP 1SV284 (TPH3) T
D4 1720000640 S.VARICAP 1SV284 (TPH3) T
D5 1720000640 S.VARICAP 1SV284 (TPH3) T
L1 6200003960 S.COIL MLF1608A 1R0K-T T
L2 6200003960 S.COIL MLF1608A 1R0K-T T
L3 6200010280 S.COIL C3328A-14NG-A T
L4 6200007000 S.COIL ELJRE 82NG-F T
L5 6200005700 S.COIL ELJRE 22NG-F T
L6 6200007000 S.COIL ELJRE 82NG-F T
L7 6200005740 S.COIL ELJRE 47NG-F [H] T
6200009180 S.COIL ELJRE R10J-F3 [L], [M] T
R1 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R2 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R3 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R4 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R5 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω) T
R6 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R7 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R8 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R13 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) T
R14 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R15 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) T
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C2 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C3 4550006770 S.TANTALUM TEESVD2 1C 476M-12R T
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C6 4030009510 S.CERAMIC C1608 CH 1H 010B-T [H] T
4030009520 S.CERAMIC C1608 CH 1H 020B-T [L] T
4030009540 S.CERAMIC C1608 CH 1H 1R5B-T [M] T
C7 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T T
C8 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C9 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C10 4030009510 S.CERAMIC C1608 CH 1H 010B-T T
C11 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C13 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C14 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C15 4030009510 S.CERAMIC C1608 CH 1H 010B-T T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C17 4610001920 S.TRIMMER TZC3Z060A110R00 T
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C22 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C23 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C24 4030009530 S.CERAMIC C1608 CH 1H 030B-T [M], [H] T
4030009920 S.CERAMIC C1608 CH 1H 050B-T [L] T
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C26 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C27 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C28 4030009510 S.CERAMIC C1608 CH 1H 010B-T [M], [H] T
4030009520 S.CERAMIC C1608 CH 1H 020B-T [L] T
C29 4030009510 S.CERAMIC C1608 CH 1H 010B-T [L], [M] only T
J1 6910008020 CONNECTOR IPS-1323 T
J2 6910008020 CONNECTOR IPS-1323 T
J3 6910008020 CONNECTOR IPS-1323 T
J4 6910008020 CONNECTOR IPS-1323 T
J5 6910008020 CONNECTOR IPS-1323 T
J6 6910008020 CONNECTOR IPS-1323 T
EP1 0910056168 PCB B 5661H
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
IC1 1110002750 S.IC TA75S01F (TE85R) T
IC2 1150001670 IC S-AU27AL (ICOM) / SC-1322 [L] T
1150001680 IC S-AU27AM (ICOM) / SC-1323 [H] T
IC3 1110002400 S.IC NJM2107F-TE1 T
IC7 1180000420 S.IC TA78L05F (TE12R) T
IC8 1180002660 S.REG µPC2910T-E1 T
Q4 1560001300 S.FET 2SK3475 (T2LICOM) T
Q7 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q8 1510000590 S.TRANSISTOR 2SA1362-Y (TE85L) T
Q9 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q10 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q11 1520000410 TRANSISTOR 2SB1143 T T
Q12 1530001940 S.TRANSISTOR 2SC2712-BL (TE85R) T
D2 1720000360 S.DIODE HSU88TRF T
D4 1720000360 S.DIODE HSU88TRF T
D5 1750000200 S.DIODE 1SS319 (TE85R) T
D6 1730002340 S.ZENER MA8047-M (TX) T
D7 1730002340 S.ZENER MA8047-M (TX) T
D13 1750000550 S.DIODE 1SS355 TE-17 T
D15 1790000720 DIODE MA29W-B T
L6 6110003850 COIL LA-587 [H] T
6110003940 COIL LA-586 [L] T
L7 6110003850 COIL LA-587 [H] T
6110003940 COIL LA-586 [L] T
L8 6200007670 S.COIL LQW2BHN10NJ01L T
L10 6110003661 COIL LA-563A T
L13 6110003661 COIL LA-563A T
L14 6200003960 S.COIL MLF1608A 1R0K-T T
L15 6200009790 S.COIL BLM31PG121SN1 T
L16 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
L17 6200009790 S.COIL BLM31PG121SN1 T
L18 6200009790 S.COIL BLM31PG121SN1 T
L19 6200005640 S.COIL ELJRE 6N8Z-F T
L20 6110003830 COIL LA-583 [L] T
6110003860 COIL LA-588 [H] T
L21 6110003830 COIL LA-583 [L] T
6110003860 COIL LA-588 [H] T
L22 6200005650 S.COIL ELJRE 8N2Z-F T
L23 6200008570 S.COIL LQW2BHN6N8D01L T
L24 6200007230 S.COIL LQW2BHN15NJ01L T
L25 6110003661 COIL LA-563A T
L26 6910000670 COIL BL01RN1A1D2B T
L27 6110003790 COIL LA-579 T
R1 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R2 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R8 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) [H] T
7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) [L] T
R11 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R12 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) T
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R15 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R16 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R19 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R20 7030000250 S.RESISTOR MCR10EZHJ 82 Ω (820) T
R21 7030000250 S.RESISTOR MCR10EZHJ 82 Ω (820) T
R22 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220) T
R23 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220) T
R25 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R26 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R28 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) [H] T
7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) [L] T
R29 7030000010 S.RESISTOR MCR10EZHJ JPW (000) [L] T
7030000140 S.RESISTOR MCR10EZHJ 10 Ω (100) [H] T
R31 7030000350 S.RESISTOR MCR10EZHJ 560 Ω (561) [H] T
R32 7030000350 S.RESISTOR MCR10EZHJ 560 Ω (561) [H] T
R38 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) T
R39 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R40 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R41 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) T
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R43 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R47 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R56 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R57 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
5 - 13
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
