[25PA UNIT] IC-FR4100 ONLY[25PA UNIT] IC-FR4100 ONLY
R58 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R59 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R60 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R61 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) T
R62 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R63 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R64 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R65 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R66 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R67 7030000010 S.RESISTOR MCR10EZHJ JPW (000) T
R68 7030003860 S.RESISTOR ERJ3GE JPW V T
R70 7030003860 S.RESISTOR ERJ3GE JPW V T
R73 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω) [L] T
7030003860 S.RESISTOR ERJ3GE JPW V [H] T
R74 7030003860 S.RESISTOR ERJ3GE JPW V T
R75 7030000010 S.RESISTOR MCR10EZHJ JPW (000) T
C1 4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L [H] T
4030018460 S.CERAMIC ERF22X 6C2H 100J D01L [L] T
C2 4030017970 S.CERAMIC ERF22X 6C2H 120J D01L T
C3 4030017970 S.CERAMIC ERF22X 6C2H 120J D01L T
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C15 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C20 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C21 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C22 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C30 4030017200 S.CERAMIC GRM31BR32J102KY01L T
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C37 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C39 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C40 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C41 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C42 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C44 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C47 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C52 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C53 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C55 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C56 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C57 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C59 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C60 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C61 4510007690 ELECTROLYTIC LXZ25VB2200 T
C67 4510007960 ELECTROLYTIC KMY25VB1000 T
C68 4510007670
S.ELECTROLYTIC
EEVHB1C100R T
C69 4510007670
S.ELECTROLYTIC
EEVHB1C100R T
C70 4510007670
S.ELECTROLYTIC
EEVHB1C100R [H] only T
C71 4510007670
S.ELECTROLYTIC
EEVHB1C100R T
C74 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C78 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C79 4030009510 S.CERAMIC C1608 CH 1H 010B-T T
C80 4030017200 S.CERAMIC GRM31BR32J102KY01L T
C82 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C83 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C88 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C89 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C90 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C91 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C92 4510007570
S.ELECTROLYTIC
EEVHB1C220UR T
C95 4510007670
S.ELECTROLYTIC
EEVHB1C100R T
C96 4510007670
S.ELECTROLYTIC
EEVHB1C100R T
C97 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C98 4030018540 S.CERAMIC ERF22X 6C2H 7R0D D01L T
C99 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L [H] T
4030018540 S.CERAMIC ERF22X 6C2H 7R0D D01L [L] T
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C102 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C103 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C104 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C105 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C107 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C108 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
C109 4550006470 S.TANTALUM TEESVB2 1D 106M8L T
C111 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C112 4030007010 S.CERAMIC C1608 CH 1H 100D-T T
C113 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C114 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C115 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C116 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C117 4030018410 S.CERAMIC ERF22X 6C2H 2R0C D01L [L] T
4030018540 S.CERAMIC ERF22X 6C2H 7R0D D01L [H] T
C118 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C119 4030018370 S.CERAMIC ERF22X 6C1H 102J D01L T
C120 4030004760 S.CERAMIC C2012 JF 1H 104Z-T T
C121 4510007660 ELECTROLYTIC LXZ25VB100 T
C122 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C123 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C124 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C125 4550006470 S.TANTALUM TEESVB2 1D 106M8L [H] T
4550006900 S.TANTALUM TEESVB2 1V 225MPS8L [L] T
C126 4550006480 S.TANTALUM TEESVA 1C 475M8L T
C127 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C129 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C130 4030018410 S.CERAMIC ERF22X 6C2H 2R0C D01L T
C131 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L
[H] only T
C132 4550002810 S.TANTALUM TEESVD2 1E 106M12L T
C133 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C134 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C135 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C136 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
J1 6510022800 S.CONNECTOR B10B-PH-SM3-TB T
J2 6510007020 CONNECTOR TMP-J01X-V6 T
T2 5910001000 TRANSFORMER TC-7 T
EP1 6910014490 TERMINAL OP-100 M3 T
EP2 6910014490 TERMINAL OP-100 M3 T
EP3 0910057024 PCB B 6029D
EP4 6910015380 BEAD B-20L-34 T
EP5 6910015380 BEAD B-20L-34 T
EP6 6910015380 BEAD B-20L-34 T
5 - 14
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
