Icom IC-FR3100 Service Manual

[50PA UNIT] IC-FR4000 ONLY
IC1 1150000180 IC M57729 / SC1027 [M] T
1150001670 IC S-AU27AL (ICOM) / SC-1322 [L] T
1150001680 IC S-AU27AM (ICOM) / SC-1323 [H] T
IC2 1110002750 S.IC TA75S01F (TE85R) T
IC3 1180001250 S.IC TA7808F (TE16L) [H] only T
IC4 1110002400 S.IC NJM2107F-TE1 T
IC5 1180000420 S.IC TA78L05F (TE12R) B
IC6 1130004200 S.IC TC4S66F (TE85R) T
IC7 1110006060 S.IC S-80820CNMC-B8F-T2 T
Q1 1560001160 S.FET 2SK3475 (TE12L) T
Q2 1530000920 TRANSISTOR 2SC3102 T
Q3 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q5 1510000590 S.TRANSISTOR 2SA1362-Y (TE85L) T
Q6 1530001940 S.TRANSISTOR 2SC2712-BL (TE85R) T
Q7 1520000410 TRANSISTOR 2SB1143 T T
Q8 1590000680 S.TRANSISTOR DTC114EUA T106 T
Q9 1590000680 S.TRANSISTOR DTC114EUA T106 T
D1 1750000200 S.DIODE 1SS319 (TE85R) T
D2 1720000360 S.DIODE HSU88TRF B
D4 1720000360 S.DIODE HSU88TRF B
D5 1730002340 S.ZENER MA8047-M (TX) B
D6 1730002340 S.ZENER MA8047-M (TX) B
D7 1730000900 S.ZENER RD12M-T1B1 T
D8 1790000620 S.DIODE MA77 (TX) T
D9 1790000620 S.DIODE MA77 (TX) T
D10 1790000620 S.DIODE MA77 (TX) T
D11 1720000360 S.DIODE HSU88TRF T
L1 6200005640 S.COIL ELJRE 6N8Z-F T
L2 6200004480 S.COIL MLF1608D R82K-T T
L3 6200005780 S.COIL 33CS-Y655LY-03K=P3 [L] T
6200005800 S.COIL 33CS-Y655LY-02M=P3 [M], [H] T
L4 6200005780 S.COIL 33CS-Y655LY-03K=P3 T
L5 6200005790 S.COIL 33CS-Y655LY-01M=P3 T
L6 6110003690 COIL LA-572 T
L7 6110003650 COIL LA-562 T
L8 6110003620 COIL LA-559 T
L9 6110003630 COIL LA-560 T
L10 6110003620 COIL LA-559 T
L13 6200005650 S.COIL ELJRE 8N2Z-F T
L14 6110003661 COIL LA-563A T
L15 6110003661 COIL LA-563A T
L16 6110003640 COIL LA-561 T
L17 6200009790 S.COIL BLM31PG121SN1 T
L18 6200009790 S.COIL BLM31PG121SN1 T
L19 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
L20 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
L21 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
L22 6200009180 S.COIL ELJRE R10J-F3 [L], [M] only T
R1 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R2 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R3 7030006250 S.RESISTOR ERJ12YJ271U (270 Ω) T
R4 7030001040 S.RESISTOR MCR50JZHJ 18 Ω (180) T
R5 7030006250 S.RESISTOR ERJ12YJ271U (270 Ω) T
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R7 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220) T
R8 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω) B
R9 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω) B
R12 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω) T
R13 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω) [H] only T
R14 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) [L], [M] T
7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω) [H] T
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R16 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R17 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R19 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R20 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) T
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R25 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R26 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R28 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R29 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R30 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) [L], [M] B
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) [H] B
R32 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) T
R33 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R34 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R35 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R39 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R43 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R44 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
[L]: LOW BAND, [M]: MIDDLE BAND, [H]: HIGH BAND
5 - 15
REF ORDER
DESCRIPTION M.
NO. NO.
[50PA UNIT] IC-FR4100 ONLY
R45 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R46 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220) T
R47 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R48 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R50 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R51 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R52 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R53 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) T
R54 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R56 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) [L], [M] T
7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) [H] T
R57 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R58 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R59 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R60 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R61 7510001660 S.THRMISTOR NTCG16 4LH 473KT T
R62 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R63 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R64 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R66 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R67 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R68 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R69 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R70 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
[L], [M] only
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C3 4030007010 S.CERAMIC C1608 CH 1H 100D-T Other T
4030007040 S.CERAMIC C1608 CH 1H 180J-T [L] T
C4 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C6 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C7 4030017200 S.CERAMIC GRM31BR32J102KY01L T
C8 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C9 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C10 4030017190 S.CERAMIC GRM31AR32J471KW01D T
C12 4030011050 S.CERAMIC GRM31M3C2H3R0CY21L [M] only T
C14 4030017890 S.CERAMIC ERF22X 6C2H 101J D01L T
C17 4030018290 S.CERAMIC ERF22X 6C2H 390J D01L T
C18 4030018050 S.CERAMIC ERF22X 6C2H 270J D01L T
C19 4030018050 S.CERAMIC ERF22X 6C2H 270J D01L T
C20 4030018170 S.CERAMIC ERF22X 6C2H 4R0C D01L T
C21 4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L[M], [H] T
4030018540 S.CERAMIC ERF22X 6C2H 7R0D D01L [L] T
C24 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L T
C25 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L[M], [H] T
4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L [L] T
C26 4030018450 S.CERAMIC ERF22X 6C2H 8R0D D01L [M]] T
4030018460 S.CERAMIC ERF22X 6C2H 100J D01L [L], [H] T
C27 4030018420 S.CERAMIC ERF22X 6C2H 5R0C D01L[L], [M] T
C29 4030018420 S.CERAMIC ERF22X 6C2H 5R0C D01L[L], [M] T
C30 4030018450 S.CERAMIC ERF22X 6C2H 8R0D D01L [M] T
4030018460 S.CERAMIC ERF22X 6C2H 100J D01L [L], [H] T
C31 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L[M], [H] T
4030018430 S.CERAMIC ERF22X 6C2H 6R0D D01L [L] T
C32 4030018030 S.CERAMIC ERF22X 6C2H 3R0C D01L T
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C39 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C40 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C41 4510007670 S.ELECTROLYTIC EEVHB1C100R T
C42 4510007940 ELECTROLYTIC KMY25VB100 [L], [M] only
C43 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C45 4030006850 S.CERAMIC C1608 JB 1H 471K-T T
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C47 4510007960 ELECTROLYTIC KMY25VB1000 T
C48 4030017190 S.CERAMIC GRM31AR32J471KW01D T
C49 4030017200 S.CERAMIC GRM31BR32J102KY01L T
C55 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C56 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C58 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C59 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C60 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C61 4510007690 ELECTROLYTIC LXZ25VB2200 T
C62 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C64 4030007170 S.CERAMIC C1608 CH 1H 221J-T B
C65 4030009530 S.CERAMIC C1608 CH 1H 030B-T [L], [M] only B
C66 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C68 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C69 4510007570 S.ELECTROLYTIC EEVHB1C220UR T
C70 4030007170 S.CERAMIC C1608 CH 1H 221J-T T
C71 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
