Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
6-16
[LOGIC UNIT] [LOGIC UNIT]
C9038 4030024900 S.CER GRM033R61A224KE90D B 60.0/55.7
C9039 4030022140 S.CER GRM033B31H102KA12D B 69.8/32.0
C9041 4030025040 S.CER GRM0332C1H220JA01D T 76.4/52.8
C9051 4030022140 S.CER GRM033B31H102KA12D B 75.7/98.6
C9052 4030022160 S.CER GRM033B31A104KE84D B 76.7/98.6
C9053 4030025040 S.CER GRM0332C1H220JA01D B 47.0/67.3
C9054 4030022140 S.CER GRM033B31H102KA12D B 46.1/67.3
C9055 4030022160 S.CER GRM033B31A104KE84D B 45.2/67.3
C9056 4030025420 S.CER GRM033R61A105ME15D B 47.9/67.3
C9057 4030022140 S.CER GRM033B31H102KA12D B 46.3/74.3
C9058 4030022140 S.CER GRM033B31H102KA12D B 39.0/82.0
C9059 4550007370 S.TAN F931V225MBABMA B 40.0/84.3
C9060 4030022140 S.CER GRM033B31H102KA12D B 38.3/86.9
C9061 4030024900 S.CER GRM033R61A224KE90D B 41.5/80.0
C9062 4030019560 S.CER GRM21BB31C106KE15L B 39.0/77.0
C9063 4030022140 S.CER GRM033B31H102KA12D B 45.3/73.0
C9064 4030019560 S.CER GRM21BB31C106KE15L B 40.8/77.0
C9065 4030019560 S.CER GRM21BB31C106KE15L B 42.5/77.0
C9066 4030019560 S.CER GRM21BB31C106KE15L B 44.3/77.0
C9071 4030022140 S.CER GRM033B31H102KA12D B 38.8/69.7
C9072 4550007370 S.TAN F931V225MBABMA B 41.5/71.3
C9073 4030022140 S.CER GRM033B31H102KA12D B 38.3/74.3
C9074 4030024900 S.CER GRM033R61A224KE90D B 41.8/67.7
C9075 4030022140 S.CER GRM033B31H102KA12D B 37.0/61.5
C9076 4030019560 S.CER GRM21BB31C106KE15L B 37.6/64.3
C9077 4030019560 S.CER GRM21BB31C106KE15L B 39.3/64.3
C9078 4030019560 S.CER GRM21BB31C106KE15L B 41.1/64.3
C9079 4030019560 S.CER GRM21BB31C106KE15L B 42.8/64.3
C9091 4030022100 S.CER GRM0332C1H100JA01D B 73.2/30.5
C9092 4030022100 S.CER GRM0332C1H100JA01D B 71.7/31.1
C9094 4030022150 S.CER GRM033B31E103KA12D B 103.4/67.0
C9095 4030022140 S.CER GRM033B31H102KA12D B 105.1/70.0
C9096 4030022150 S.CER GRM033B31E103KA12D B 106.4/69.8
C9097 4030025910 S.CER GRM033B31C393KE84D B 105.4/65.6
C9098 4030025700 S.CER GRM033R71E472KE14D B 56.6/31.3
C9099 4030025700 S.CER GRM033R71E472KE14D B 56.6/30.1
C9100 4030025700 S.CER GRM033R71E472KE14D B 56.6/28.9
C9121 4030022140 S.CER GRM033B31H102KA12D B 49.2/61.3
C9122 4030022150 S.CER GRM033B31E103KA12D B 49.2/60.4
C9123 4030022160 S.CER GRM033B31A104KE84D B 49.2/59.5
C9124 4030022160 S.CER GRM033B31A104KE84D B 49.2/58.6
C9125 4030022160 S.CER GRM033B31A104KE84D B 48.8/54.1
C9126 4030022160 S.CER GRM033B31A104KE84D B 48.8/49.8
C9127 4030022160 S.CER GRM033B31A104KE84D B 49.2/38.5
C9128 4030022140 S.CER GRM033B31H102KA12D B 32.6/55.5
C9129 4030022150 S.CER GRM033B31E103KA12D B 32.6/50.0
C9130 4030022160 S.CER GRM033B31A104KE84D B 33.5/55.5
C9131 4030022160 S.CER GRM033B31A104KE84D B 33.5/50.0
C9151 4030022080 S.CER GRM0332C1H101JA01D B 12.3/33.7
C9167 4030022150 S.CER GRM033B31E103KA12D B 11.7/33.7
C9168 4030025700 S.CER GRM033R71E472KE14D B 18.3/26.5
C9169 4030022150 S.CER GRM033B31E103KA12D B 18.0/25.5
C9201 4030022080 S.CER GRM0332C1H101JA01D B 158.5/73.9
C9203 4030025700 S.CER GRM033R71E472KE14D B 155.8/73.9
C9204 4030025700 S.CER GRM033R71E472KE14D B 185.7/78.1
C9205 4030022120 S.CER GRM0332C1H470JA01D B 143.8/73.2
C9206 4030022120 S.CER GRM0332C1H470JA01D B 147.2/73.2
C9207 4510010450 S.ELE EEEFT1C102AP B 168.2/80.9
C9208 4510010450 S.ELE EEEFT1C102AP B 179.0/80.9
C9251 4510008120 S.ELE 16 CE 100 BS B 200.0/59.3
C9252 4030022160 S.CER GRM033B31A104KE84D B 194.6/64.1
C9253 4030022150 S.CER GRM033B31E103KA12D B 191.1/64.1
C9254 4510007310 S.ELE 16 CE 10 BS B 186.8/58.2
C9259 4510007310 S.ELE 16 CE 10 BS B 186.8/70.9
C9260 4030025700 S.CER GRM033R71E472KE14D B 191.4/76.9
C9261 4030025700 S.CER GRM033R71E472KE14D B 194.3/76.9
C9262 4510008120 S.ELE 16 CE 100 BS B 200.0/72.0
C9301 4030025700 S.CER GRM033R71E472KE14D B 155.4/52.3
C9302 4510008110 S.ELE 16 CE 22 BS B 157.0/61.6
C9303 4030025700 S.CER GRM033R71E472KE14D B 153.5/62.5
C9304 4510007310 S.ELE 16 CE 10 BS B 148.7/47.3
C9305 4510007310 S.ELE 16 CE 10 BS B 156.5/48.6
C9306 4510007280 S.ELE 50 CE 2R2 BS B 148.7/38.6
C9307 4510007310 S.ELE 16 CE 10 BS B 173.4/49.2
C9308 4510008980 S.ELE EEEHB1C470P B 162.5/49.7
C9309 4510008600 S.ELE EEE1CA4R7NR B 178.2/49.2
C9310 4030025700 S.CER GRM033R71E472KE14D B 149.8/52.3
C9311 4030025700 S.CER GRM033R71E472KE14D B 152.2/62.5
C9312 4510009250 S.ELE EEEFK1C471P B 164.3/63.1
C9313 4030025860 S.CER GRM0332C1H121JA01D B 150.8/53.8
C9401 4030022160 S.CER GRM033B31A104KE84D B 117.7/28.7
C9402 4510008120 S.ELE 16 CE 100 BS B 18.2/8.0
C9403 4510007310 S.ELE 16 CE 10 BS B 64.2/16.7
C9404 4510008120 S.ELE 16 CE 100 BS B 11.1/8.5
C9405 4510007310 S.ELE 16 CE 10 BS B 100.1/15.9
C9406 4030025700 S.CER GRM033R71E472KE14D B 15.7/16.8
C9407 4030025700 S.CER GRM033R71E472KE14D B 16.2/24.0
C9408 4030025700 S.CER GRM033R71E472KE14D B 14.8/13.0
C9411 4030025700 S.CER GRM033R71E472KE14D B 16.0/19.2
C9414 4030025700 S.CER GRM033R71E472KE14D B 60.7/18.3
C9415 4510008110 S.ELE 16 CE 22 BS B 143.4/37.9
C9416 4030025700 S.CER GRM033R71E472KE14D B 45.8/19.0
C9417 4510008980 S.ELE EEEHB1C470P B 41.0/16.7
C9419 4030022150 S.CER GRM033B31E103KA12D B 98.2/34.6
C9421 4030022160 S.CER GRM033B31A104KE84D B 20.7/27.4
RL9151 6310000110 S.REL AGQ200S12 B 17.7/33.8
J9051 6510027570 S.CON B7B-ZR-SM4-TF (LF) (SN) B 68.6/95.4
J9052 6510027111 S.CON 08FLT-SM2-TB (LF) (SN) (M) B 79.8/96.3
J9053 6510031070 S.CON AYF534035 T 56.9/64.5
J9091 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 155.4/32.3
J9092 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 207.1/26.9
J9151 6510014961 S.CON B2B-ZR-SM4-TF (LF) (SN) B 6.9/34.1
J9201 6510022031 S.CON B10B-ZR-SM4-TF (LF) (SN) B 151.1/84.2
J9401 6510022621 S.CON
10FMN-BMTTR-A-TBT (LF) (SN)
B 7.7/19.3
J9402 6510022621 S.CON
10FMN-BMTTR-A-TBT (LF) (SN)
B 120.4/14.2
DS9001 5030004580 LCD RFE430V-AZH-DNN-000
DS9071 5040003950 S.LED SSC-WH104-NZ T 10.9/15.8
DS9072 5040003950 S.LED SSC-WH104-NZ T 47.2/10.2
DS9073 5040003950 S.LED SSC-WH104-NZ T 69.6/9.8
DS9074 5040003950 S.LED SSC-WH104-NZ T 92.0/9.8
DS9075 5040003950 S.LED SSC-WH104-NZ T 114.4/10.2
DS9076 5040003950 S.LED SSC-WH104-NZ T 186.4/28.7
DS9077 5040003950 S.LED SSC-WH104-NZ T 207.1/29.4
DS9078 5040003950 S.LED SSC-WH104-NZ T 210.4/80.2
DS9079 5040003950 S.LED SSC-WH104-NZ T 210.4/55.2
DS9080 5040003950 S.LED SSC-WH104-NZ T 197.4/55.2
DS9081 5040003950 S.LED SSC-WH104-NZ T 184.4/55.2
DS9082 5040003950 S.LED SSC-WH104-NZ T 155.4/52.7
DS9083 5040003950 S.LED SSC-WH104-NZ T 147.3/69.9
DS9084 5040003950 S.LED SSC-WH104-NZ T 163.7/86.3
DS9085 5040003950 S.LED SSC-WH104-NZ T 184.4/80.2
DS9086 5040003950 S.LED SSC-WH104-NZ T 197.4/80.2
S9071 2260002740 S.SWI LS8J2M-T T 47.2/16.2
S9072 2260002740 S.SWI LS8J2M-T T 69.6/15.8
S9073 2260002740 S.SWI LS8J2M-T T 92.0/15.8
S9074 2260002740 S.SWI LS8J2M-T T 114.4/16.2
S9075 2260002740 S.SWI LS8J2M-T T 10.8/21.3
S9076 2260002740 S.SWI LS8J2M-T T 155.4/90.0
S9077 2260002740 S.SWI LS8J2M-T T 143.4/78.0
S9078 2260002740 S.SWI LS8J2M-T T 155.4/78.0
S9079 2260002740 S.SWI LS8J2M-T T 167.4/78.0
S9080 2260002740 S.SWI LS8J2M-T T 155.4/66.0
S9081 2260002740 S.SWI LS8J2M-T T 147.1/52.7
S9082 2260002740 S.SWI LS8J2M-T T 163.7/52.7
S9083 2260002740 S.SWI LS8J2M-T T 184.4/86.4
S9084 2260002740 S.SWI LS8J2M-T T 197.4/86.4
S9085 2260002740 S.SWI LS8J2M-T T 210.4/86.4
S9086 2260002740 S.SWI LS8J2M-T T 184.4/73.9
S9087 2260002740 S.SWI LS8J2M-T T 197.4/73.9
S9088 2260002740 S.SWI LS8J2M-T T 210.4/73.9
S9089 2260002740 S.SWI LS8J2M-T T 184.4/61.4
S9090 2260002740 S.SWI LS8J2M-T T 197.4/61.4
S9091 2260002740 S.SWI LS8J2M-T T 210.4/61.4
S9092 2260002740 S.SWI LS8J2M-T T 184.4/48.9
S9093 2260002740 S.SWI LS8J2M-T T 197.4/48.9
S9094 2260002740 S.SWI LS8J2M-T T 210.4/48.9
S9095 2260002740 S.SWI LS8J2M-T T 186.4/34.9
S9096 2260002740 S.SWI LS8J2M-T T 208.4/34.9
EP9001 6910019100 S.BEA MPZ1608S101AT B 88.5/69.7
EP9002 6910025230 S.BEA BLM15BD221SN1D B 52.2/67.4
EP9003 6910025230 S.BEA BLM15BD221SN1D B 51.3/70.8
EP9004 6910025230 S.BEA BLM15BD221SN1D B 62.4/70.8
EP9005 6910025230 S.BEA BLM15BD221SN1D B 56.1/72.3
EP9006 6910025230 S.BEA BLM15BD221SN1D B 53.5/70.8
EP9007 6910025230 S.BEA BLM15BD221SN1D B 61.0/70.8
EP9008 6910025230 S.BEA BLM15BD221SN1D B 56.8/70.8
EP9009 6910025230 S.BEA BLM15BD221SN1D B 54.6/70.8
EP9010 6910025230 S.BEA BLM15BD221SN1D B 57.5/72.3
EP9011 6910025230 S.BEA BLM15BD221SN1D B 58.2/70.8
EP9012 6910025230 S.BEA BLM15BD221SN1D B 61.7/72.3
EP9013 6910025230 S.BEA BLM15BD221SN1D B 59.6/70.8
EP9014 6910025230 S.BEA BLM15BD221SN1D B 60.3/72.3
EP9015 6910025230 S.BEA BLM15BD221SN1D B 55.8/67.4
EP9016 6910025230 S.BEA BLM15BD221SN1D B 54.9/67.4
EP9017 6910025230 S.BEA BLM15BD221SN1D B 53.1/67.4
EP9018 6910025230 S.BEA BLM15BD221SN1D B 51.3/67.4
EP9019 6910025230 S.BEA BLM15BD221SN1D B 63.1/72.3
EP9020 6910025230 S.BEA BLM15BD221SN1D B 54.0/67.4
EP9021 6910025230 S.BEA BLM15BD221SN1D B 58.9/72.3
EP9022 6910025230 S.BEA BLM15BD221SN1D B 63.8/70.8
EP9051 6910019100 S.BEA MPZ1608S101AT B 47.7/71.3
EP9121 6910019100 S.BEA MPZ1608S101AT B 47.7/62.1
EP9201 6910012350 S.BEA MMZ1608Y 102BT B 156.0/75.2
EP9202 6910012350 S.BEA MMZ1608Y 102BT B 158.8/75.2
EP9203 6910012350 S.BEA MMZ1608Y 102BT B 144.3/74.5
EP9204 6910012350 S.BEA MMZ1608Y 102BT B 147.6/74.5
EP9206 6910014730 S.BEA MPZ2012S331A-T B 185.8/76.3
EP9207 6910014730 S.BEA MPZ2012S331A-T B 149.9/77.7
EP9208 6910014730 S.BEA MPZ2012S331A-T B 153.4/77.7
EP9209 6910014730 S.BEA MPZ2012S331A-T B 151.6/77.7
EP9401 6910014730 S.BEA MPZ2012S331A-T B 12.1/14.3
EP9402 6910024660 S.BEA MPZ2012S102AT B 13.4/16.1
EP9403 6910024660 S.BEA MPZ2012S102AT B 13.4/19.3
