ICP HMH024KD1 - Page 57

1 12K Heaing Model 6871A10036E 6.8K 5.1K 1K OPEN 39K O O O O O O
2 12K Cooling Model 6871A10036F 6.8K 5.1K 1K OPEN 39K X X X X X X
3 9K Heaing Model 6871A10036G 6.8K 10K 6.8K 3K OPEN O O O O O O
4 18K Heaing Model 6871A10036C 6.8K 10K 5.1K 6.8K 12K O O O O O O
5 18K Cooling Model 6871A10036D 6.8K 10K 5.1K 6.8K 12K X X X X X X
6 24K Heaing Model 6871A10036A 3K 2K 6.8K OPEN 3K O O O O O O
7 24K Cooling Model 6871A10036C 3K 2K 6.8K OPEN 3K X X X X X X
8 9K Cooling Model 6871A10036H 6.8K 10K 6.8K 3K OPEN X X X X X X
- 57 -
(2) MAIN PWB ASSY(Outdoor Unit)
• PWB ASSY SVC PART LIST
NO MODEL P/No.
OPTIONAL FUNCTION
OR4H OR5H OR6H OR7H OR 8H FUSE
RY-
HEATER
RY-
4WAY
RY-FAN
CN-
4WAY
CN-
FAN
CN-TH
125V
3.15A
250V
3.15A
