Parts List(12K)
- 64 -
131410 CHASSIS ASSY 3141A20003D 1 1 R
135311 GRILLE ASSY, DISCHARGE(INDOOR) 3531A10023T 1 1 R
135312 GRILLE ASSY, FRONT 3531A10030 1Y 1Z R
135314 GRILLE ASSY, INLET 3531A10032 1W 1X R
146811 MOTOR ASSY, STEP 4681AR2727H 1 1 R
152302 FILTER(MECH), A/C 5230A20004A 2 2 R
159901-1 VANE,HORIZONTAL 5990A30006A 1 1 R
159901-2 VANE,HORIZONTAL 5990A30007A 1 1 R
249951 CONTROL BOX ASSY, INDOOR 4995A20143 1N 1P R
263230 THERMISTOR ASSY 6323A20003A 1 1 R
267110 REMOTE CONTROLLER ASSY 6711A20025M 1 1 R
268712 PWB(PCB) ASSY, DISPLAY 6871A30009E 1 1 R
268714 PWB(PCB) ASSY, MAIN 6871A10035 1F 1E R
342800 BEARING 3H02821B 1 1 R
346810 MOTOR ASSY, DC 4681AR2295H 1 1 R
35211B TUBE ASSY, TUBING 5211AR7066B 1 1 R
352150 HOSE ASSY, DRAIN 5251AR2575A 1 1 R
354212 EVAPORATOR ASSY, FINAL 5421A20031X 1 1 R
359011 FAN ASSY, CROSS FLOW 5901AR6141C 1 1 R
733010 PLATE ASSY, INSTALL 1H00843A 1 1 R
LOCATION PART NAME PART No.
Q/TY
HMC012KD1 HMH012KD1
REMARKS
("R" means
service parts)
