Parts List(9K, 12K)
- 68 -
552116 TUBE ASSY,REVERSING 5211A20140 1F 1G R
552202 VALVE,REVERSING 5220AR3084B 1 1 R
552203-1 VALVE,SERVICE 2H02479H 1 1 R
5220A20005A 1 1 R
552203-3 VALVE,SERVICE 2H01890L 1 1 R
5220A20003A 1 1 R
553000 HEATER,SUMP 5300AR2915D 1 1 R
554031 CONDENSER ASSY,BENT 5403A20019 1B 1P R
5403A20026 1D 1B R
554160 COMPRESSOR SET 2520UKAC2BA 1 R
2520UKWC2FA 1 R
2520UKCC2AA 1 R
2520UKSC2AA 1 R
559010 FAN ASSY,PROPELLER 5901A10004A R
561410 COIL ASSY,REVERSING VALVE 6141AR3851G 1 1 R
567502 O.L.P 6750U-L029A 1 R
6750U-L031A 1 R
6750U-L046A 1 R
6750U-L049A 1 R
649950 CONTROL BOX ASSY,OUTDOOR 4995A10038 1A 1B 1C 1D R
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10036 1H 1G 1F 1E R
W0CZZ CAPACITOR,DRAWING 0CZZA20001 1N 1L R
6120AR2194 1F 1K R
552111 TUBE ASSY,CAPILLARY 5211A20095F 1 R
5211A20141 1A 1D R
5211A20133D 1 R
261704 TRANSFORMER,POWER 6171AQ3198B 1 1 1 1 R
430410 BASE ASSY,OUTDOOR 3041A20008 1J 1F 1D 1F R
435511 COVER ASSY,CONTROL(OUTDOOR) 3551AR7184R 1 1 1 1 R
437210 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A20027B 1 1 1 1 R
437212 PANEL ASSY,REAR(OUTDOOR) 3721A20026 1A 1B 1A 1B R
546810 MOTOR ASSY,OUTDOOR 4681A20004R 1 1 1 1 R
550140 ISOLATOR,COMP 4H00982E 3 3 3 3 R
LOCATION
PART NAME PART NO.
"REMARKS("R"
means service parts)
Q'TY
HMC009KD1 HMH009KD1 HMC012KD1 HMH012KD1
To Next Page
