Physical
Size 7.45" L x 5.57" W x 1.52" H
(18.92 cm L x 14.15 cm W x 3.86 cm H)
Weight
Module 1.6 lbs. (0.73 kg.)
Shipping 3 lbs. (1.4 kg)
Construction RoHS Compliant
Temp erat ure
Operating -10 °C to +65 °C
Storage -40 °C to + 70 °C
Humidity 0-90% RH non-condensing
Shock/Vibration Normal handling
Connectors
GPIB GPIB 24 pin ribbon
with metric studs.
Ethernet RJ-45
Power 9 to 32 Vdc @ 4 VA
RFI/EMI CE Certied
EEC Standards EN 55024:2010
and EN 55022:2010
Firmware Field upgradable
Included Accessories
Instruction Manual
CD-ROM with support information.
LAN Crossover Cable.
UL/CSA/VDE approved 115/230 ±10% AC
Power Adapter provided with plugs for US, UK,
Europe, Japan, Australia and China
4865B SPECIFICATIONS
Ethernet - GPIB Controller with 115/230 VAC adapter, universal plug set, Manual and CD-ROM 4865B
Ethernet - GPIB Controller OEM Board 115897
GPIB Accessary Cables See separate data sheet
Rack Mounting Kits (holds one or two 4865Bs). See separate data sheet Single - 114210, Dual - 114211
ORDERING INFORMATION Part Number
Copyright 2016 ICS Electronics, Specications subject to change without notice
Supported Standards
IEEE 488.1 Capabilities:
The 4865B's IEEE-488.1 capabilities are deter-
mined by the communication link to the instru-
ment. For VXI-11 instruments they are:
AH1, SH1, T6, L4, SR1, RL2, PP0, DC1,
DT1, C0 and E2
E2 Drivers incorporate power up/down
protection.
4865B Address 0 to 30 [4]
488 Bus Performance
Long term GPIB transfer rates are limited by
the LAN data transfer rate, the Client-computer
performance, the GPIB controller and the LAN
instrument or device. Internal delays vary with
t h e a m o u n t o f d a t a t r a n s f e r r e d a n d 4 8 6 5 B 's a c t i v -
ity when the message was received.
Short term transfer rates:
GPIB to 4865B >260 kbyte/sec
4865B to GPIB >180 kbyte/sec
Command times:
*IDN? query 17 ms typical (VXI-11)
*IDN? query 3 ms typical (raw socket)
*CLS command 8.5 ms typical (VXI-11)
Supported GPIB (IEEE-488.1) Commands
Either converted into the equivalent VXI-11 rpc
or replaced by a user designated string.
Device Clear
Device Trigger
Local
Remote
Serial Poll
VXI-11 Capabilities
Fully VXI-11.3 compliant
VXI-11.3 Client side
Channel types Data channel
Instrument links 64 max
Locking By instrument link
RPC Protocol
Conforms to ONC RPC Version 2
Ethernet Interface
Type IEEE 802.3 compliant
Auto-MDIX
Speeds 10BaseT (10 Mb/s)
100BaseT(100 Mb/s)
IP Address Static or DHCP (AutoIP)
Factory setting DHCP with AutoIP.
D e f a u l t s t o 1 6 9. 2 5 4 . 4 8 . 6 5 i f
no DHCP server response.
Net Mask 255.255.0.0
Interface name inst0
07/16
Companion Instrument
The 4865B supports a single instrument that is
VXI-11.3 compatible or that uses raw sockets.
GPIB Controller Requirements
G P I B C o n t r o l l e r n e e d s t o b e I E E E - 4 8 8 . 2 c o m p l i -
ant. Device messages must be terminated with the
IEEE-488.2 new line terminator (linefeed with
EOI asserted) or with just EOI asserted if the LAN
instrument does not require a terminator.
Computer with an IEEE 802.3 LAN interface and
a web browser for conguring the 4865B.
Internal WebServer
The internal WebServer provides HTML web
pages for viewing and setting the 4865B's con-
guration.
Controls and Indicators
CONTROLS
Power Front-panel switch
LAN Reset Rear-panel push-button
LEDs
PWR Power on
LAN Unit connected to an active
network or network device.
ACT Transferring messages to/
from the network.
RDY Blinks when looking for an
instrument. Steady on when
linked to an instrument
TALK 4865B is addressed to talk
LSTN 4865B is addressed to listen
SRQ 4865B asserting SRQ on the
GPIB bus.
ERR Unit has detected an error
The VXI-11 Specication is available from the VXI Consortium at http://www.vxibus.org/specs.html?q=node/206
or from ICS's website at http://www.icselect.com/vxi_spec.html
