ICS Tunnel Master Jr Manual

TUNNEL MASTER JR MANUAL
Wash Configuration 44
Wash Settings
Menu Item
Function
Menu items and an explanation of their function.
Step Action Screen Displays
1 Press the [MENU] button
from the main screen display
[1] Shift Break [4] View Counts
[2] Wet Down Wash [5] Print Reports
[3] Configure Wash
2 Press the numeric key “3” to
select the Configure Wash
menu option.
[1] Services [4] Wash Settings
[2] Outputs [5] Set Date Time
[3] Outputs Lists [6] Set Password
3 Press the numeric key “4” to
select the Wash Settings
menu option.
PulseLength _ _ _ _ _ _ _ _ _ _
F1=PREV F2=NEXT F3=RESET F4=SAVE
4 Using the numeric key pad
enter the desired setting for
Pulse Length
Note: Review button
functions on page 31.
PulseLength 7.75_ _ _ _ _ _
F1=PREV F2=NEXT F3=RESET F4=SAVE
5 Press the “F4” button on the
display pad to accept and
save the entry.
PulseLength 7.75_ _ _ _ _ _
F1=PREV F2=NEXT F3=RESET F4=SAVE
6 Press the “F2” button to
advance to the next setting
to enter
MinCarLength _ _ _ _ _ _ _ _ _ _
F1=PREV F2=NEXT F3=RESET F4=SAVE
7 Repeat steps 4 – 6 until all
settings have been
programmed.
MaxCarLength _ _ _ _ _ _ _ _ _ _
F1=PREV F2=NEXT F3=RESET F4=SAVE
8 Press the [MENU] button to
return to the previous menu
screen
[1] Services [4] Wash Settings
[2] Outputs [5] Set Date Time
[3] Outputs Lists [6] Set Password
