3. Packing List
A7 / V7 A7 / V7
1-1. Overview
1. Introduction
2. Specifications
96% or greater
Four way bill insertion acceptance.
Numerous interfaces available.
Easily Install & Maintain.
High Acceptance Rate up to 96%.
A7/V7 Series is a bill acceptor which features not only high-security
module with bill box but also outstanding recognition, acceptance
rate up to 96% or even greater.
1-2. Features
Main
Accessory
Bill Acceptor
Harnesses: see 5-1
A7/V7 Installation Guide
A7/V7 DIP Switch Setting Guide
Approx. 3 seconds to stack
Indoor
12V- Standby : 5 W
Operation: 24 W
Maximum: 36 W
Four-way acceptance
See Page.3
Approx. 100 bills ( 80~120)
200 bills (200~300)
400 bills (350~450)
800 bills (750~850)
Standard Pulse, 5V Enable, ICT Protocol,
MDB, GPT Parallel
Approx. 1.25kg
General
Mechanical
Acceptance Rate
Transaction Speed
Installation
Power Consumption
Bill Insertion
Interface
A7: 12V DC (11.4~12.6 V DC)
117V AC (105.3~128.7 V AC)
V7: 12V DC (11.4~12.6 V DC)
24V AC (21.6~26.4 V AC)
34V DC (20V~42.5 V DC)
Power Source
Operation Temperature: 0°C~55°C
Storage Temperature: -30°C~70°C
Humidity: 30%~85RH (no condensation)
Operation Environment
Outline Dimension
Bill Capacity
Weight
Electrical
Note: The incomplete bills such as extremely dirty, wet, broken or wrinkled
ones are excluded.
Bill Acceptor Bill Acceptor
1
www.ictgroup.com.tw
2
www.ictgroup.com.tw
