2bay 2.5" SATA internal enclosure
IB-2227 Series
http://www.icybox.de
54
6. LED Indication
Action LED Indication
Power on LED shines blue
HDD access LED blinks purple
7. Assembly of HDD and into PC
Attention!
a. Please connect the LED cable, which is delivered in the package. Otherwise the LED has no function!
b. When necessary please put on the "HDD-Pin-Protector" as showed in 7.1 to avoid mechanical
damage of the Pins.
7.1 7.2
7.3 7.4
LED: 4Pins
Data: 7Pins
Power: 15Pins
8. Function
Each HDD is only ("1 to 1") passed through to Mainboard. The two HDD remain independent from each
other and the computer sees 2 independent drives.
HDD 1
HDD 2
Mainboard
Host 1
Host 2
