Manual IB-367-CPD+
Manual IB-367-CPD+
Attention: A new HDD/SSD must first be initialized, partitioned and
formatted by the operation system to be displayed by the system.
Attention: Please await end of read/write operations before discon-
necting the HDD/SSD to avoid data lost.
If the hard disc will not be recognized instantly by the operating system,
please check:
• If the driver software has been installed.
• If the HDD/SSD has been initialized, partitioned and formatted.
LED-Function
The LED shines blue for power and blinks blue for drive access
USB Power Delivery and alternate mode
4K
Power Delivery 2.0
The USB Power Delivery 2.0 feature a 5/9/12 V power
supply via the USB Type-C
™
cable with up to 24 W in total. If a
notebook or handheld device is used as host it can be charged
simultaneously.
Note: The Power Delivery function must be supported by the
hosts Type-C
™
interface!
If the host reboots while connected, the IB-367-CPD+ must be
turned off and on as well to ensure further charging.
DisplayPort
™
alternate mode
Just connect a screen via the mini DisplayPort
™
interface and
the host device should automatically recognize an additional
screen.
Note: Your host device must support DisplayPort
™
alternate
mode on the chosen USB Type-C
™
interface!
More Pixels
(4K@30 Hz)
More Speed
(10 Gbps)
Smart Charge
(24 W)
Notebook
