OUTPUT Flash mpx:
- Video Composite out is standard Yellow RCA jack
- S Video (Y/C) out is standard mini 4 pin din connector.
- Headphone out, stereo100 mWatt, 36 Ohm on 3.5 mm jack.
- Audio line out, 2 V p/p stereo on 2 RCA jacks (red and white).
- 14 Watt speaker output, 8 ohm on 4 mini screw on terminal.
- Audio line out and speaker out and headphone out are simultaneously controlled by
the volume up/down.
- Relay output is available on Busy and Common terminals. The output is Dry Contact,
Normally Open rated at 1 Amp.
INPUT Flash mpx:
- 8 + 1 UP input on screw on terminals, plug in removable.
- Input 1 to 8, to trigger short momentarily to ground.
- Input 9 to 16, to trigger short both an Input and UP input momentarily to ground.
- Volume UP and Volume Down input, to adjust the volume short it momentarily to
ground. Volume is adjustable from 0 to 16. Default setting is 4.
ENCLOSURE Flash mpx:
- Aluminum enclosure (desktop), 7.25” W X 4.25” D X 1.2” H.
- Weight is approximately 1.2 lbs.
- Shipping weight with Power Supply & cord is 3 lbs.
Power supply Flash mpx:
- 120 – 240VAC Universal switching power supply complete with a detachable PC
style power cord.
- Power output is 12VDC, 30 watt.
