Page
Installation instructions 3
List of Warnings 4
Operation 5
Maintenance 6
Parts Drawing 7
Parts List 8
Wiring 9
Warranty 10
Anchor windlass
Hawse pipe/chain stripper
Windlass cover
Footswitches
Solenoids
Circuit breaker
Instructions
Electric drill
17/32 drill bit
2” hole saw
Jig saw
Wrench set
Screwdrivers
Caulking & gun
Grease
Mounting bolts for the windlass base, four 3/8 bolts
Mounting bolts for the chain stripper/ hawse pipe, four 1/4 bolts
Mounting screws for the windlass cover, four # 10 wood screws
Patience
For identification purposes please record the serial number, model number
and voltage of this anchor windlass and keep it in an accessible place. This in-
formation will be necessary if you need to contact IDEAL for any reason.
2
Contents
Packing
List
Tools
and
Materials
Required
