IDEAL 5009-1 - Installation; Transport and Lifting Safety

- 11 -
B
A
~1200 kg
(2630 lbs)
>110 cm
The transport safety device (A) and (B) must
be mounted when the machine is transported
lengthwise. The machine must be transported
from the rear.
Make sure the pallet-jack is centred under the
machine.
Do not lift up the machine from the
operating side.
Do not lift the machine more than necessary
© risk of tipping.
Aufstellung
•
Installation
•
