IDEC GT3A Series

GT3S Series
Timers
832
www.idec.com
Switches & Pilot LightsDisplay LightsRelays & SocketsTimersTerminal Blocks
Circuit Breakers
General Specifi cations
Operation System Solid state CMOS circuitry
Operation Type Star-delta
Time Range
Star side: 0.05 to 100 sec
Star-delta switching time:
0.05, 0.1, 0.25, 0.5 sec
Rated Operational Voltage 100 to 240V AC (50/60Hz)
Operating Temperature -10 to +50˚C
Storage Temperature -30 to +80˚C
Operating Humidity 45 to 85% RH
Voltage Tolerance 85 to 264V AC
Repeat Error ±0.2%, ±10 msec
Voltage Error ±0.2%, ±10 msec
Temperature Error ±0.2%, ±10 msec
Setting Error ±10% maximum
Reset Time 500 msec maximum
Insulation Resistance 100MΩ minimum
Dielectric Strength
Between power and output terminals: 2,000V AC, 1 minute
Between contacts of different poles: 2,000V AC, 1 minute
Between contacts of the same pole: 750V AC, 1 minute
Vibration Resistance 100 m/sec
2
(Approx. 10G)
Shock Resistance
Operating extremes: 100m/sec
2
(Approx. 10G)
Damage limits: 500m/sec
2
(Approx. 50G)
Power
Consumption
(Approx.)
Typ e
GT3S-1
2.3VA (100V AC, 60Hz),
4.0VA (200V AC, 60Hz)
Typ e
GT3S-2
2.3VA (100V AC, 60Hz),
3.8VA (200V AC, 60Hz)
