WindO/I-NV4 User’s Manual 5-15
3 Base Screen
5
Screen
● Options Tab
■ Background Color
Select the screen’s background color (color: 256 colors, monochrome: 16 shades). Click this button to open the color
palette. Select color with the color palette.
■ Overlay with Base Screen
Configure this section to display the Base Screen by overlaying screens.
When Overlay with Base Screen is configured, the background color for the Base Screen specified as the
background is displayed.
1 to 5: Select these to display the Base Screen by overlaying screens.
No.: Enter the overlay screen’s screen number (1 to 3000).
Coordinates X, Y: Specify the display location of the overlay screen in coordinates. The coordinates can be set
in the range (Screen size - 1 dot).
The origin is the upper-left corner of the screen and the X- and Y-coordinates correspond to
the upper-left corner of the overlay window.
(0, 0)
X
Y
Base screen
Overlay screen
To Next Page
