IDEC SmartRelay installation and wiring

IDEC SmartRelay Manual 24

2.2.2 Wall-mounting

For wall-mounting, first slide the mounting slides on the rear

side of the devices towards the outside. You can now

wall-mount the IDEC SmartRelay by means of two mounting

slides and two

M4 screws (tightening torque 0.8 to 1.2 Nm).

Mounting slides

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com
