IEI Technology AFL-08B-N270 User Manual

AFL-08B-N270 User Manual
Page 44
Figure 2-15: Tighten the Panel Mounting Clamp Screws
2.6.3 Cabinet and Rack Installation
The AFL-08B-N270 panel PC can be installed into a cabinet or rack. The installation
procedures are similar to the panel mounting installation. To do this, please follow the
steps below:
NOTE:
When purchasing the cabinet/rack installation bracket, make sure it is
compatible with both the AFL-08B-N270 panel PC and the rack/cabinet
into which the AFL-08B-N270 is installed.
Step 1: Slide the rear of the AFL-08B-N270 panel PC through the rack/cabinet bracket
until the aluminum frame is flush against the front of the bracket (
Figure 2-16).
