5 SPECIFICATIONS
SPECIFICATIONS
1 Regulatory
EN55022:1994 Radiated Emissions Class B
EN55022:1994 Conducted Emissions Class B
2 Susceptibility Compliance
EN61000-4-3:1996 Electromagnetic Field Susceptibility 1kHz AM, 80%, 3 V/m
EN61000-4-2:1995 Electro Static Discharge 4kV Contact, 8kV Air
EN61000-4-6:1996 Conducted RF Immunity 3 VRMS, 1kHzAM, 80%
EN61000-4-4:1995 Electrical Fast Transient 1 kV PL, 0.5 kV SL
3 Safety Compliance
EN 60950 Note: PCB material to meet and indicate UL 94V0 flammability
rating.
4 Environmental Conditions
Temperature (Operating)
0
o
C to +40
o
C
Temperature (Storage)
-20
o
C to +70
o
C
Humidity (Operating) 10% to 80% RH
Humidity (Storage) 5% to 91% RH
5 Dimensions & Weight
Dimensions
(without cable)
48.8mm (W) x 62.2mm (L) x 33.7mm (H)
Cable length 1.5m
Weight 120g (approximately)
