6
1.
Reverse the door
The appliance door can be tted to open to either the left or the right depending on its location.
The appliance will have to be tilted and supported in order to carry this out. It is advisable to get some
help during this procedure.
Important: Do not lay the appliance at as this may damage the coolant system. Take care when
tting and tightening screws.
To change the direction of the door, please follow these instructions:
1. Ensure the appliance is unplugged and empty.
2. Remove the 2 Screws on the back of the top cover (Fig 1).
3. Lift the rear of the lid and push forward to remove from the front
locators. The top hinge now is accessible (Fig 2).
4. Unscrew the top door hinge located on the top of the door and then
remove the top hinge that is holding the door in place. (Fig 3)
5. With help, carefully tilt the unit backwards
and rest the unit on something solid
to stop slipping.
6. Lift the door off the hinge pin and place in
a safe place where it will not get damaged
7. Remove the bottom bushing and bottom
bushing cap and t them on the opposite
side (Fig 4).
8. Unscrew the bottom hinge (Fig 5).
9. Remove the levelling foot and t on the
opposite side (Fig 6).
10. Screw the bottom hinge on the opposite side
loosely (Fig 7).
2.
4.3.
5.
6. 7.
