Function description ICF18, ICF32, ICF40, ICF60, ICF80DZ
14
5.2 Operating and display elements
Lid latches (fig. 2, page 4)
Operating panel (fig. 3, page 4)
Connection sockets (fig. 4, page 5)
Item Description Explanation
1ON
OFF
Switches the cooler on or off when the button is pressed for
between one and two seconds
2
POWER
“P”
Status indication
LED lights up green: Compressor is on
LED lights up orange: Compressor is off
LED flashes orange: Display switched off automatically
due to low battery voltage
3 ERROR LED flashes red: Device is switched on but not
ready for operation
4 – Display, shows the information
5 SET Selects the input mode
– Temperature setting
– Celsius or Fahrenheit display
– Set battery monitor
– Set brightness of display
6 DOWN – Press once to decrease the value
7 UP + Press once to increase the value
Item Description
1 Connection socket AC voltage supply
2 AC fuse holder
3DC fuse cover
4 Connection socket DC voltage supply
Igloo ICF18, ICF32, ICF40, ICF60, ICF80DZ_OPM_4445104001_APAC_en_202x-xx-xx.book Page 14 Thursday, September 28, 2023 6:55 PM
