Draco tera
216 2020-02-26
In order to disconnect existing connection between CON and CPU
Devices proceed as follows:
1. Click on the port that is to be disconnected by using the right mouse
button.
2. Select the Disconnect function in the popup that appears. The
connected ports will be immediately disconnected. At the same time
all further connections of the extenders assigned to the involved
devices will be disconnected.
Pos: 125 /806-IHS E/Betrieb/Umsc haltung von einzelnen Exte ndern in Devices/ 480_Umsch altung mit der Makr o-Liste @ 17\mod_15032 94954798_6.doc @ 186596 @ 2 @ 4
6.4 Switching via Macro List
Next to executing macros via function keys <F1>-<F16>, they can also be
executed via Macro List in the OSD. At the same time this specific list
offers the possibility to see the content of the various macros including the
single commands before executing them. There are displayed 16 of the
total 32 macros per page.
You have the following option to to use the Macro List:
