Rear View
Installation
Removable Hex Tool
Hex Screws for Monitor Installation
Monitor Retaining Brackets
Viewfinder
Hex Tool Retaining Magnet
1. Remove monitor retaining brackets with included hex tool
2. Slide in DH5e monitor from the rear
3. Re-install monitor retaining bracket
1
2
3
4
5
1
3
3
2
4
22
2
5
NOTE:
You can also use the hex
tool to tighten the cable
lock screw.
