ATTACHING THE BARNDOOR
The iLED312-v2 light can attach quickly and easily to barndoors. Simply slide the barndoor along the
diffuser slide until it locks into place. To release, pull down the knob and slide the barndoor out.
www.ikancorp.com 713-272-8822
iLED312-v2
ILED312-v2 Bi-color Flood Light QUICKSTART GUIDE
Barndoor Slide
Diffuser Slide
Barndoor
Diffuser
Release Knob
